LED high power PAR light is designed by mslighting Co., Ltd. It adopts in 216PCS of 1W/3W RGB, 144*4W RGBW4in1, 72*10W RGBW 4in1, which is the most advanced lamp as light sources. It is new generation green high technology product. It projects long distance, big angle, and abundant colors. It brings people new vision sense, which makes people feel they are in a changeable color world.
The nice design is good for dispelling heat very well and long life. Project angle can be adjusted randomly. The base is with holes, which are facility for orientation and fitting.
It is widely used in stage show, casino, advertisement, outside wall of mansion etc. It is controlled by controller with DMX; The effect can be gradual change, jump change, color glitter, random change, and alternate gradual change and so on. Perfect cast light beam provides architecture designers and light designers abundant imagine space.
Model: LED 2002/2002A/2002b/2002c/2002d
Voltages:
100V/120V/200V/220V /230V/240VAC, 50/60Hz
Power consumption:
700W@220V
LED: Manufacturers rated LED life 50000 hours
Colours:
RGB/w/a colours mixing
Linearly colour temperature correction
Dimmer: 0-100% linearly adjustable
Strobe: 1~20f. P. S
Beam angle: Beam(1/2maximum) 1/2 15 optional (8degree 25 degree 45 degree)
Control:
DMX512, 3 pin interfaces
3CH/4CH/6CH/7CH
Wireless DMX signal transmission can choose
DMX512, master /slave mode, sound, auto
Other functions: Brightness level control
DMX mode, setting status, operation mode and user memory data can be transmitted by synchronous control
Housing: High-intensity extruding aluminum, IP44
Work environment temperature: -20° C~40° C
Weight: 43kg
|
Model1: LED 2002 |
216*1W RGBW/RGB (54R+54G+54B+54W / 72R+72G+72B) |
|
Model2: LED 2002A |
216*3W RGBW/RGB (54R+54G+54B+54W / 72R+72G+72B) |
|
Model3: LED 2002B |
144*4W RGBW 4IN1 Multi-Color (144*4W RGBW 4IN1 Multi-Color) |
|
Model4: LED 2002C |
72*10W RGBW 4IN1 Multi-Color (72*10W RGBW 4IN1 Multi-Color) |
|
Model5: LED 2002D |
144*5W RGBW/RGB (36R+36G+36B+36W / 48R+48G+48B) |
|
Housing Material |
Aluminum |
|
Housing Color |
Black/White |
|
Aperture Cover |
Aluminum |
|
Operating voltage |
90-130V AC / 176-254V AC |
|
Output voltage |
DC 24-36V |
|
Control Modes |
Direct DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronization |
|
Lamp Luminous Efficiency(lm/w): |
99% |
|
Usage: |
Theatres, stage , robust housing |
|
Certification: |
CE,EMC, LVD, RoHs |
|
LED Life Time |
80000-100,000 hours |
|
Beam Angle |
6-120degree to choose |
|
Power Consumption |
216/1200W |
|
Light Projecting Distance |
5-300M |
|
IP Rating |
Indoor |
|
Operating Temperature |
-20ºC-+45 ºC |
|
Power In: |
Fixed |
|
CRI (Ra>): |
95 |
|
warranty: |
2 year |
|
Compatibility: |
|
1. Color Range:16.7 million additive RGB colors; continuously variable intensity (256×256×256=16777216) |
|
2. Dimming 0-100%with regulated constant color control |
|
3.Strobe: 10 Flashed per second (any color) |
|
4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable and Save function. |
|
5. 8 channel Mode and 5channel Mode would change each other in every light |
|
6. 8CH Mode DMX Value |
CH 1 _ General dimmer (1-255, from dart to light) |
|
CH 2_ Red (1-255, Dimmer, from dart to light) |
|
CH 3 _ Green (1-255, Dimmer, from dart to light) |
|
CH 4_Blue (1-255, Dimmer, from dart to light) |
|
CH 5_White (1-255, Dimmer, from dart to light) |
|
CH 6_Amber (1-255, Dimmer, from dart to light) |
|
CH 7_ Strobe & Color change/ color gradual change open |
|
CH 8 _Strobe & Color change& color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast) |
|
7. 5CH Mode DMX Value |
CH 1_ Red (1-255, Dimmer, from dart to light) |
|
CH 2 _ Green (1-255, Dimmer, from dart to light) |
|
CH 3_Blue (1-255, Dimmer, from dart to light) |
|
CH 4_White (1-255, Dimmer, from dart to light) |
|
CH 5_Amber (1-255, Dimmer, from dart to light) |
|
8.Control modes |
0: Sound activity mode |
|
1. DMX control mode |
|
2. Adjusting the color manual |
|
3. Adjusting the brightness manual |
|
4. Adjusting the strobe manual |
|
5. Adjusting the strobe speed manual |
|
6. Master-slave control mode, as the master |
|
7. Sound activity synchronization mode |
|
8. Adjusting color's gradual change manual |
|
9. Adjusting gradual change's speed. |
|
9. Thermal: |
Maximum ambient temperature: 40° |
|
Maximum housing temperature: 60° |
|
|
|
|
