Design based on:
A: 24V 8M Height 65W LED Solar Street Lighting System
B: 11-12 Hrs Full Power Lighting Mode, High Power LED, High Brightness.
C: Yearly Averaged Solar Radiation: 5.0kWh/m2/day
D: Back up 3-4Days no-sun days.
Details:
1. Pole Height: 8M Galvanized, 80*180mm, 3.50mm Thickness. Plastic Coated.
2. Solar Modules: 130W*2PC, For Poly Type, Lifespan: 20-25 Years,
Warranty: Workmanship for 3 Years, 90% of Minimum Warranted Power Output Over 12 Years, 80% Over 20 Years
3. Battery: Gelled Type, 150Ah/12V*1PC, Deep Cycle, Lifespan: 5-8 Years
4. Battery Box: Plastic material, at the bottom of the pole.
5. Light source: 65W LED, Cool White, 7800LM, IP65, Lifespan: 50000-100000 Hrs
6. LED Head for 65W LED
7. Charge Controller: 15A/24V with Protect function.
8. Mounting Parts, Cable, Screws, Fittings,
This model Solar street lamps, Design based on solar radiation 5.0
Getting more information on 65W LED Solar Street Lamps, mail or call us please.
| 8m 65w solar led street lights | 11-12Hrs 3-4 Nights Lighting. |
Solar Panel: Lifespan:20-25 years | 130W*2PC for 24V Lighting, 17% Efficiency,
Poly Crystalline Silicon. High Efficiency. Adding Aluminum Frame, Tempered Glass. |
Gelled Battery Lifespan:5-8 years | 150Ah/12V*1PC, Sealed Type, Gelled. Deep cycle. Maintenance Free. |
Intelligent Solar Controller, PWM Type, Lifespan:5-10 years | 15/24V*1PC, Automatic Light and Time Control. Over-charging/discharging Protection. Reverse-connection Protection. |
Light source: High Power LED Lifespan: >80000Hrs, | 65W*1PC LED, White Color,140LM/W,>30Lux,6500K, IP65,120 Degree Angle. |
Lamp Housing: Lifespan: More than 20 years | Die-casted Aluminum, IP65, High transmittance & density toughened glass. |
Pole: Lifespan: More than 20 years | 8M Height,Steel, Hot-Dip Galvanized. With Arm, Bracket, Flange, Fittings, Cable, Etc
Plastic Coated, Rust Proof. Resistant to Wind: ≥150KM/H. |
Yangzhou Bright Solar Solutions Co., Ltd., Established in 1997, an ISO 9001: 2000, TUV, IEC, CE&EN, RoHS, SONCAP, CCPIT, SASO and CCC approved manufacturer.
Overseas Exploration and Popularity:
We had successfully sold our solar street lights and solar panels to overseas markets more than 50 Countries such as the USA, Canada, UK, Greece, France, Italy, Australia, Turkey, Jordan, Saudi Arabia, Iraq, UAE, India, Philippines, Pakistan, Cambodia, Taiwan, Nigeria, Ghana, Congo, South Africa, Mexico, Haiti, etc.
For the Future:
With advanced manufacturing & testing equipments, our factories are growing better and better. We hope to cooperate with more partners and distributors to develop more business to create prosperous win-win partnerships. OEM is available. Welcome your inquiry mail or call.
Main Products:
Solar Street Lights & Solar Street Lighting & LED Solar Street Lighting;
Solar Garden Lights & Solar Landscape Lights;
Solar Panel & Solar Modules.
Small Solar Home System & Solar Home Kits.
Attention: We are good at
1: Designing, producing, installing solar 10W-120W Solar LED street lights
2: Designing, producing 10W-240W LED Lamp for outdoor street and road using.
3: Producing solar panel below 310W
4. Solar Battery 7Ah-300Ah/12V
5. Solar Home Kits 3W-5000W System
OEM Service for solar lighting and PV panel is available.
Welcome your inquiry of solar outdoor lights and solar home lights.
