LED Strobe light, LED High Power strobe Light, LED Stage Light, LED Effect Light, DMX LED Light, LED Color Change Light, LED WASHER, LED light, LED Lighting
|
Specification: |
|
Model |
LED 07B (48*1W) |
LED 07C(48*3W) |
LED 07D (30*3in1) |
|
Housing Material |
Iron |
Iron |
Iron |
|
Housing Color |
Black |
Black |
Black |
|
Aperture Cover |
Aluminum |
Aluminum |
Aluminum |
|
Operating voltage |
90-130V AC / 176-254V AC |
90-130V AC / 176-254V AC |
90-130V AC / 176-254V AC |
|
Power |
Switch Power Supply |
Switch Power Supply |
Switch Power Supply |
|
LED current |
320mA |
680mA |
680mA |
|
Control Modes |
Direct DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronization |
Direct DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronization |
Direct DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronization |
|
DMX Channel |
6CH |
6CH |
6CH |
|
Connector |
3-PinXLR (In and Out) |
3-PinXLR (In and Out) |
3-PinXLR (In and Out) |
|
NO.of LED |
48*1W LEDS (16R/ 16B/ 16G) |
48*3W LEDS (16R/ 16B/ 16G) |
30x3in1 LEDS |
|
LED Life Time |
80000-100,000 hours |
80000-100,000 hours |
80000-100,000 hours |
|
Beam Angle |
25°/30° |
25°/30° |
25°/30° |
|
Power Consumption |
60W |
160W |
160W |
|
Light Projecting Distance |
20-25M |
30-35M |
30-35M |
|
IP Rating |
Indoor |
Indoor |
Indoor |
|
Operating Temperature |
-20 ºC -+45 ºC |
-20 ºC -+45 ºC |
-20 ºC -+45 ºC |
|
Dimensions |
L460*W155*H135 mm |
L460*W155*H135 mm |
L460*W155*H135 mm |
|
Weight |
3.40KGS |
3.40KGS |
3.40KGS |
|
Packing Dimension |
L530*W200*H280 mm |
L530*W200*H280 mm |
L530*W200*H280 mm |
|
Gross Weight |
4.00KGS |
4.00KGS |
4.00KGS |
|
Compatibility: |
|
1. Color Range: 16.7 million additive RGB colors; continuously variable intensity (256×256×256=16777216) |
|
2. Dimming 0-100%with regulated constant color control |
|
3.Strobe: 10 Flashed per second (any color) |
|
4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable. |
|
5. 6CH DMX Value |
CH 1 _ General dimmer (1-255, from dart to light) |
|
CH 2_ Red (1-255, Dimmer, from dart to light) |
|
CH 3 _ Green (1-255, Dimmer, from dart to light) |
|
CH 4_Blue (1-255, Dimmer, from dart to light) |
|
CH 5_ Strobe & Color change/ color gradual change open |
|
CH 6 _Strobe & Color change& color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast) |
|
6.Thermal |
Maximum ambient temperature: 40° |
|
Maximum housing temperature: 60° |
MS Lighting is a professional stage lighting manufactory in China, Our products are LED Light, moving head light(spot/wash, 150W-1200W), DMX scannner, effect lights, disco lights, laser etc.
Our products are very popular by professional from all walks of life; It makes the perfect stage effect with the others stage lighting products. We have excellent quality products and the best after-sales service.
The aim of our work is your satisfaction
This is the good factory that your first choice.
