4.5m Road Lamp IP65 Aluminum LED Street Garden Lights

Brief Specification for 4M pole 15W Solar Garden Light design based on Africa's average solar radiation condition 5.0KWH,Lighting hours: 11-12 Hrs/Day*3-4 days
1. Pole Height: 4M, Diameter: 76*132mm, Thickness: 3.00mm
   Plastic coated on HDG pole, resistant to wind: 150KM/H
2. Applicable light source: 15W LED, 1500LM,Lifespan:>80000Hrs.
3. PV Module: High efficient 60W*1PC.
4. Gelled battery: 60Ah*1PC, Fee Maintence, Deep Cycle, Sealed Type.
5.Battery Box: Engineer Plastic, Bury under ground
6. Controller: 10A/12V Automatic control by microcomputer

Detailed Specification for 4M pole 15W Solar Garden Light
Part Name and Lifespan	Technical Specification
Solar Panel: Lifespan:20-25 years	60W*1PC Polycrystalline. High Efficiency. A-class Adding Aluminum Frame, Tempered Glass.
Gelled Battery Lifespan:5-8 years	60Ah/12V*1PC, Gelled battery, Sealed Type. Deep cycle. Maintenance Free
Intelligent Solar Controller Lifespan:5-10 years	10A/12V,IP68. Automatic Light and Time Control Over-charging/discharging Protection Reverse-connection Protection Switch on Automatically with Light Sensor; Switch off after designed Hours later.(11-12 Hrs)
Light source: High Power LED Lifespan: More than 50000-100000Hrs	15W LED, White Color,1500LM/PC,6500K,IP65, High Power, High Brightness.
Lamp Housing: Lifespan: More than 20 years	Die-casted Aluminum, IP65 High transmittance & Density toughened glass,
Battery Box:	Engineer plastic,underground of the pole.
GI Pole System: Lifespan: More than 20 years	4M Height, tapered Pole, Steel, Hot-Dip Galvanized. Plastic Coated, Rust Proof, With Arm, Bracket, Flange, Fittings, Cable, Etc Resistant to Wind: ≥150KM/H

Solar Garden Light Working Principle:
1. LED solar street light relies on solar energy, which is clean, endless and
   environment-friendly.
2. The system is mainly composed of solar panel, light source, controller and
    free-maintenance battery.
3. In daytime, when there is sunshine, the solar panel can convert the solar energy to
   electric energy and store it in the battery. At night or rainy or cloud condition, the
   battery shall supply power for normal lighting.
4. The controller can judge the brightness of daylight and automatically switch on the
   light. The whole process is operating in completely automatic mode, without human
   action.
DX SOLAR Brief Introduction:
Yangzhou Dingxin Photoelectric Technology Co., Ltd ,  Established in 1997, an ISO 9001: 2000, TUV, IEC, CE&EN, RoHS, SONCAP CCPIT and CCC approved manufacturer.

Overseas Exploration and Popularity:
We had successfully sold our solar street lights and solar panels to overseas markets more than 50 Countries such as the USA, UK, Canada, Germany, Spain, Greece, Italy, Sweden, France, Portugal, Cyprus, Romania, Croatia, Middle East, New Zealand, Fiji, Norway, Belgium, France, Italy, Australia, Turkey, Jordan, Iraq, UAE, India, Pakistan, Bangladesh, Qatar, Yemen, Singapore, Philippines, Cambodia, Nigeria, Congo, Mexico, etc.

Please note, our best competitive products:
10W-120W Solar LED Street Lights&5W to 30W Solar Garden Light;
10W-240W LED Lamp and LED Housing;
Solar Panel below 300W;
24Ah/12V~250Ah/12V&300AH/2V-3000AH/2V Solar Battery
After-sales Service
1. LED solar street lights should be used under normal condition. The warranty of the
   quality is based on correct preservation, installation, usage and maintenance.
2. It's not included in the warranty scope if the products damage is due to improper
   installation, product regulations violation or damaged by human.
3. For the quality problems during the warranty period, our company will choose the
   best methods of repair exchange (parts) or replace the products and etc.
4.Choosing DX SOLAR LED street light design from here:
First:
1).the power of your required LED light?
2).the height of the pole?
3).how many hours/night the light can work?

Second: If you have no idea on the above question, we could design for you,
please inform us:
1). What's the width of road?
2). What's your request on the power of the light source?

The end:
Please choose your favorite model from our website or the catalogue.

Applications
Solar Street Lighting System  Solar Security Light
Solar Main Road Light            Solar Garden Light
Solar Freeway Light               Solar Campus Light
Solar Avenue Light                 Solar Pedestrian Street Light
Solar Sidewalk Light               Solar Jogging and Bike Path Light
Solar Military Bases Light       Solar Gate Light
Solar Path Light                     Solar Park Light
Solar Parking Lot Light           Solar Campus Light
Solar Driving way Light           Solar Pedestrian Street Light
Solar Remote Area Light         Airport Solar light
Solar Driving way Light           Solar Boat Dock LightSome material cost, labor cost may be charged properly for extended service.
