2015 Alibaba cheap discounted price outdoor led display sceen
Shenzhen outdoor full color LED display manufacture
Specifications
1)Long durability
2)High reliability
3)Low maintenance cost
4)Energy dfficient
According to the feedback of clients, there are a few problems existing in current LED panel market, such as Difficulty of Maintenance, High Cost for Maintenance Service, Extra Large Space needed for Rear Maintenance and etc. In order to reach clients' best interest, Shenzhen Myled has developed P10, P16 and P20 Dual-channel Maintenance Full Color LED Display to solve all the problems mentioned above. Clients can provide maintenance service, either standing in front of LED panel, or standing in rear space of LED Screen; in this case, the maintenance fee has decreased tremendously and the maintenance service becomes a lot easier.
The Main Features of Front&Rear Dual-channel Maintenance LED panel:
1. Screws become unnecessary between LED modules and cabinets; without screws, the demounting and mounting process becomes a lot easier. Within a few seconds, the LED module can be demounted off the cabinet so that the working efficiency is highly enhanced.
2. Cabinets become a lot thin and light, with thickness 115mm and weight 26kg in maximum. Compared with similar products in the existing market, it is more light and thinner.
3. More space has been saved, compared with large space needed for maintenance service within tradtional LED Display.
Why Us:
1. We have 8 years' experience,professional engineers,sales and workers service for you,
all goods examined before delivery,Professional QC team .
2. We can promise you a short lead time
3. We have factory and can offer you direct highest cost-effective price
4. We have a variety of customized products to satisfy your different requests.
Specification | PH10 | PH12 | PH16 | PH20 | PH25 | PH31.25 |
Pixel Configuration | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 2R1G1B | 4R2G2B |
Density of pixel | 1/4 scan | 1/4 scan | Static | Static | Static | Static |
Module Resolution | 16*16(W*H) | 16*16(W*H) | 16*8(W*H) | 16*8(W*H) | 8*8(W*H) | 8*8(W*H) |
Pixel Pitch | 10mm | 12mm | 16mm | 20mm | 25mm | 31.25mm |
Best Viewing Distance | >10mm | >12mm | >15mm | >20mm | >25mm | >30mm |
Module Size(mm) | 160*160*25 | 192*192*25 | 256*128*30 | 320*160*30 | 200*200*30 | 250*250*25 |
Cabinet Size(mm) | 960*640*150 | 800*800*150 | 1024*768*150 | 1280*960*150 | 1600*1200*150 | 1000*1000*150 |
Weight | 35Kg | 40Kg | 45Kg | 60Kg | 65Kg | 50Kg |
Working Voltage | AC220/110 ± 10%, 47~63Hz |
Waterproof Rate | IP65 |
Maxim Power | ≤1000W | ≤750W | ≤1650W | ≤1650W | ≤1000W | ≤800W |
Average Power | ≤450W | ≤300W | ≤700W | ≤700W | ≤425W | ≤350W |
Horizontal Angle | 120° | 120° | 120° | 120° | 120° | 120° |
Vertical Angle | 60° | 60° | 60° | 60° | 60° | 60° |
Brightness | ≥8000 cd | ≥7500 cd | ≥7000 cd | ≥6000 cd | ≥5500 cd | ≥5000 cd |
Pixel density | 10000 | 6400 | 3906 | 2500 | 1600 | 1111 |
Contrast Ratio | 6000:1 | 6000:1 | 6000:1 | 6000:1 | 6000:1 | 6000:1 |
Color processing | 16 bit | 16 bit | 16 bit | 16 bit | 16 bit | 16 bit |
Color | 281 trillion | 281 trillion | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
Frame Rate | 60 MHz |
Working Temperature | -20ºC to +60ºC |
Operating humidity | 20% to 90% |
Lifespan (50% Brightness) | 100,000 hours |
Located in Baoan District, Shenzhen Myled Optech is an professional LED display manufacturer which is dedicated to LED display R&D; Production, sales, marketing and one stop solution for customers mainland and international. Myled provides consulting, installation, training and sales services for customers. We always regard customers as the company life line.
Shenzhen Myled Optech focus on indoor and outdoor full color LED display, LED curtain display, mesh, indoor and outdoor single and bicolor LED display manufacturing. We have established business relationship with customers in South America, Euro, and Asia etc. And win a good reputation among customers all over the world. And we provide full solution for Government, Telecom, Hotel, airport, bus station, stadium, and cinema and financial center, etc. Over the past years, we have finished some important LED display project for South American and China Mainland.
Quality is the most important theme for Myled and welcome to contact, and visit our company.
We hold the truth that better quality, better price and better sales services are our company culture.
