Voltage / frequency: 90V-240V/50-60Hz
Bulbs: LED 13 6 red / 6 Green / 6 Blue
Power: 54W
Control signal: DMX 512, in sets at the automatic procedure
Channel: 12 CH, DMX512 channel control
Color: 16.7 million kinds of colors changes
Adjusts the light: 0-100 electron adjusts the light, various colors may alone move also may mix the color tone
Strobe: 1-25/second high speed strobe, but single color mixes the color strobe
Low power consumption
Super luminance, with the efficiency of ordinary power bulbs, rich and splendid color
DMX-512 control signal, 12 standard channels
The housing is made of streamline fashionable PC engineering plastic after once casting
Wide range super tiny smooth scanning, horizontal scanning angle reaches 450° And vertical 270° , the scanning precision reaches 8bit and 16bit, with smooth and precise positioning, additionally, the scanning speed is adjustable
Infinite RGB color mixed system
The light beam angle would choose from 6° - 60°
High speed electronic strobe reaches 1-18 times/second
Total light adjustment control channel can control 3 main color channels simultaneously
The digital display on the control panel can be reversed for 180° , applicable for horizontal or vertical use of moving head
With the functions of synchrony movement and music control
Meet CE standard, UL standard and GB7000.15-2000 standard.
|
Electronic Dimmer: |
0-100% linear dimmer |
|
Electronic Strobe: |
1-30 flashes/second |
|
LED Life Time |
80000-100,000 hours |
|
Power Consumption |
18W |
|
Light Projecting Distance |
5-50M |
|
IP Rating |
Indoor |
|
Operating Temperature |
-20ºC-+45 ºC |
|
Power In: |
Fixed |
|
CRI (Ra>): |
95 |
|
Accessories: |
Power cable,power con cable,omega clamp, XLR DMX Signal cable,Safety Rope |
|
Cooling: |
Entire casing as heat sink plus noiseless fans |
|
Flicker Free |
Refresh Rate >1000 Hz |
|
Key point: |
Temperature-protected handly |
|
Thermal: |
Maximum ambient temperature: 40° |
|
Maximum housing temperature: 60° |
|
CH1 |
RGB full color change |
|
CH2 |
RED color change |
|
CH3 |
GREEN color change |
|
CH4 |
BLUE color change |
|
CH5 |
The control for strobe and speed |
|
CH6 |
RGB Rainbow Effect |
|
CH7 |
X scanning |
|
CH8 |
Y scanning |
|
CH9 |
Dimmer |
|
CH10 |
X adjusting |
|
CH11 |
Y adjusting |
|
CH12 |
X/Y speed |
|
|
|
|
Packaging & Delivery |
|
|
Packaging Detail: |
Standard Export packing by carton or OEM package |
|
Delivery Detail: |
2-5 days for sample , 5-12 days for mass quantity order |
|
Shipping |
By DHL, UPS, FedEx, EMS or TNT, boat ,Air. |
|
Guarantee |
we guarantee that all the product have been shipped after the testing , if there any damage caused in transit , we can not control the entire process , if so , we are happy to communicate with you friendly solution. |
|
Items have 2 YEAR warranty. ( Except lamp-house). |
|
Note |
We can declare it as a 'GIFT/Sample' with a lower value Which you may reduce tax. But This lower price does not reflect the total price you paid or the market value of the product |
