Input voltage: AC100~220V 50~60Hz
Power: 240W
Light source: CREE America 10W 4in1 led chip = Bright light
Quantity 18pcs led chip(RGBW 4in1)
Rated life 80000~100000 hours
High luminous efficiency, no radiation, low power consumption, no flicker
Color: RGB linear color mixing, build-in multi-function
Lens angle: 150 standard (80, 250, 300, 450, 600 optional)
Dimmer: 0~100% linear dimmer
Strobe: 1~10 times / sec
Control mode: International standard DMX512 signal, 3-pin connect, 4channels, DMX512 signal / master-slave / sound control, DMX address optional; Self-programming mode, Self-running mode, External control mode
Other function: IP address code extension, DMX address code extension, Build-in program
Environment temperature: -200 C ~400 C
Waterproof rating: Casting Aluminum shell, IP66
Display: LED display
Carton Size: 300*300*380mm
Net weight: 7.8 kg
|
5 channles |
6 channles |
7 channles |
8 channles |
13 channles |
Function |
|
|
CH 1 |
CH 1 |
CH 1 |
CH 1 |
Dimming |
|
CH 1 |
CH 2 |
CH 2 |
CH 2 |
CH 2 |
RED |
|
CH 2 |
CH 3 |
CH 3 |
CH 3 |
CH 3 |
GREEN |
|
CH 3 |
CH 4 |
CH 4 |
CH 4 |
CH 4 |
BLUE |
|
|
|
CH 5 |
CH 5 |
CH 5 |
WHITE |
|
|
|
|
CH 6 |
CH 6 |
Marco Function |
|
|
|
|
|
CH 7 |
Strobe |
|
|
|
|
|
CH 8 |
Internal Programming |
|
|
|
|
|
CH 9 |
Internal Programming Speed Adjustment |
|
|
|
|
|
CH 10 |
Dimming Speed |
|
|
|
|
|
CH 11 |
ID Address |
|
CH4 |
CH5 |
CH6 |
CH 7 |
CH 12 |
Zooming |
|
CH5 |
CH6 |
CH7 |
CH 8 |
CH 13 |
Zooming Speed |
