| Price: | US $ 1184/Square Meter |
|---|---|
| Trade Terms: | FOB,EXW |
| Min Order: | 1/Box |
| Pay Type: | T/T,Paypal,Western Union |
| Prod Model: | PH8 SMD LED display |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: | 256mm*128mm |
| Cabinet Size: | 768mm*768mm |
| Brightness: | More Than 1500 CD/Sqm |
| Cabinet Weight: | 35kg |
| LED Type: | SMD3528 |
| Warranty: | 2 Years |
| Display Type: | LED Video Display |
| Tube Chip Color: | Full Color |
| Display Function: | Video Display |
| Scanning Mode: | 1/4 Scan |
| Certification: | CCC |
| Pixel Configuration: | 1R,1G,1B |
| Application: | Shopping Guide |
| IP Rating: | IP43 |
| Pixel Pitch: | 8mm |
| Pixel Density: | 15625dots/Sqm |
| System Operating Platform: | Windows98/Me/2000/Nt/XP/Win7 |
Wide Viewing Angle Horizontal and vertical viewing angle is 140 degrees, pictures and videos of the display can be viewed by more viewers. | |||||
|---|---|---|---|---|---|
| High Brightness and Brightness Adjustable The brightness is more than 1500nits/sqm, and can be adjusted automatically, it saves power cost. | |||||
| High Refresh Rate The refresh rate is more than 1000HZ, it is flicker-free when live broadcast. It fully meets the needs of professional camera shooting. | |||||
| Professional-grade Connectors LEDA indoor SMD led displays use professional grade connectors for fast installation, safe and stable connection. | |||||
| Fast and Easy to Maintain LEDA indoor SMD display can be front service design, it can be maintenaned from front. | |||||
| Quality Guaranteed The product is designed and produced in strict compliance with international standards, such as CE, ROHS. | |||||
| Model | P8 | ||||
|---|---|---|---|---|---|
| Model No.: | LEDA-IW-P8 | ||||
| Pixel Pitch | 8mm | ||||
| LED Type | SMD3528 | ||||
| Pixel Configuration | 1R1G1B | ||||
| LED Driving Method | 1/8 Scan | ||||
| Module Pixel | 32*16 (W*H) | ||||
| Module Size | 256*128MM | ||||
| Cabinet Pixel | 96*96 (W*H) | ||||
| Cabinet Size | 768*768MM | ||||
| Cabinet Weight | 35KG | ||||
| Max. Power Consumption | ≤1000W/ | ||||
| Ave. Power Consumption | ≤500W/ | ||||
| Hor. Viewing Angle | 140° | ||||
| Verti. Viewing Angle | 140° | ||||
| Brightness | ≥1500 cd/ | ||||
| Pixel Density | 15625/ | ||||
| Protection Level | IP43(Front & Back) | ||||
| Processing | 16 bit | ||||
| Colors | 281 trillion | ||||
| Refresh Rate | ≥1000HZ | ||||
| Frame Rate | 60fps | ||||
| Lifetime | 100,000 Hours | ||||
| Power | AC220/110 ± 10%, 47~63Hz | ||||
| Operating Temperature | -20ºC to +60ºC | ||||
Operating Humidity | 20% to 90% | ||||
Brightness Level | Manual 100 levels,automatically 16 levels | ||||
| Certifications | CCC, FCC, CE, ROHS, UL, ETL | ||||
