Sending Card:
Linsnrv901
Received Card:
Linsnrv901
Driving IC:
5020
Power Supply:
AC110/220 ± 15%
Display Type:
LED Video Display
Tube Chip Color:
Full Color
Display Function:
Video Display
Scanning Mode:
1/8 Scan
Certification:
CCC
Pixel Configuration:
1R,1G,1B
Application:
Shopping Guide
IP Rating:
IP43
System Operating Platform:
WIN2000
Pixel Pitch:
8mm
Pixel Density:
15625DOT/M&Sup2
Product Description
ITEMS PARAMETERS Pixel Pitch 8mm Size of Module 256*128mm Density of Pixel 15625per sqm Pixel Composition 1R1G1B LED Encapsulation SMD3524 Resolution of Module 32*16 Power Consumption of Module Below 30W The Optimum View Distance 5-15m The Optimum View Angle H: 160 V: 120 Maximum Power Consumption 2000W per sqm Driving Components MBI502 X G X or other Compatible IC (Optional) Driving Method 1/8Scan Constant Driving Frame Frequency Over 360Hz Refresh Rate Over 600Hz Luminnance of White Balance Over 2500CD per sqm Environment Temperature for Working -20- +50(Optional)-30- +50 Unit: Centi-degree Working Voltage 220V± 10%(or)110V± 10% Mean Time Between Failure Over 5000(hours) Life Span Over 100000(hours) Out-of-Control Rate Below 0.0001 Input Signal RF/S-Video(etc. ) Brightness Adjustment 256 levels of each color(R\G\B)can be adjusted automatically and 100 levels of each color can be adjusted manually Control System PCTV non-linear editting card + DVI display card + main controling card+optic ribre transmission(Optional) China Manufacturer We specialise in LED display, LED screen, LED sign, LED display board, full color LED display, rental LED display, curtain LED display, moving LED display etc. Welcome your contact!
Viewing angle: 160 degrees Working temperature: : (-20--60) degrees Control mode: Dynamic scanning, VGA sync Scanning frequency: ≥ 140Hz/s Out of control DOT: No Communication distance: ≤ 100m(twisted pair, no relay) Working voltage: Mains supply(220V± 10%) Maximum power consumption(w/m2): 800 Life span: ≥ 100000hours
Cabinet Size(WxH)
1024 × 896mm
Cabinet resolution
128dots ×112dots
Cabinet pixels
14,336dots
Viewing angle
120°/90°
Protective Grade
IP65
Average Power consumption
300 Watt/m²
Max Power consumption
850 Watt/m²
Best View distance
>8M
Weight(kg/pc)
65kg/m²
Material
Steel
Included
1. Power Modules
2. Fans
3. External Power cables & connectors
4. Mounting/locking plates between cabinets
5. Inter-connecting cables & ribbons (both power and signal)
Xinhongxiang Optoelectronics (Shenzhen) Co., Ltd. As one of the most leading LED Products manufacturer in Shenzhen China, covering 10 000 square meters, register capital high up to 30 million CNY, is one high-tech enterprise focus on researching, producing, sale and service of LED products, . Nowadays Xinhongxiang owns fully automatic production lines, independent purifying workshop, researching center, most advanced production and inspection equipments, which guarantee the quality of the LED products. All the products have exported more than 100 countries, such as USA, Mexico, Canada, Brazil, Chile, Argentina, Panama, Colombia, Germany, France, Sweden, Italy, Spain, Russia, Poland, Turkey, Ukraine, South Africa, Egypt, Saudi Arabia, Singapore, Thailand, India etc
Developing History:
From 1996 to 2010, Xinhongxiang Optoelectronics (shenzhen) Co., Ltd, mainly involved in LED encapsulation and LED Display.
Since 2010, owe to enlarge the company scale and build up self-owned brand, Xinhongxiang focus on LED lighting, Shenzhen BESDLED Co., Ltd focus on LED display, business involved in indoor and outdoor LED Encapsulation, LED Display and LED Lighting Products.
LED Display:
Full Color Indoor and outdoor LED Display, single or dual basic color LED signs, LED Curtain, LED Dance Floor, Rental LED Display,
LED Lighting:
LED Bulb, LED Tube, LED Spotlight, LED DownLight, LED Panel Light, LED Street etc,
Comparing with many of LED Manufactures, xinhongxiang owns the following advantages to be your best choice for long term cooperation partner.
1, Fully automatic production lines
Xinhongxiang owns the entire LED manufacturing line, from original Semiconductor to LED chip, then assemble to LED display and LED lighting products.
2, Advanced production equipment
SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP LED, Spectrum and Color Separation Machine, LED oven, Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and humidity programmable tester, luminance meter etc. Are equipped for our LED Product production.
3, Many Certification approved to clear up the trade barriers
CE, FCC, UL, RoHS, CCC, ISO9001: 2000 etc are obtained.
4, Strong R&D Team
Xinghongxiang absorb many talents, with more than 500 staffs, and including more than 100 engineers and technician, which paves the way for R&D for new products and excellent sales service
5): After-Service,
Principles: Response in time, solve problem ASAP and ensure the use.
Period: During warranty period, free of all maintenance charges;
