| Prod Model: |
UP-MH575C |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Display: |
LCD Display |
| Cooling System: |
3PCS Fans |
| Color: |
14 Colors+White |
| Gobo: |
8 Gobos + White |
| Prism: |
3-Faced Prism |
| Material: |
Aluminum Alloy |
| Emitting Color: |
Changeable |
| Control Channel: |
16CH |
| Strobe: |
Combined Type Double Strobe |
| Control Mode: |
Dmx Signal Control |
| IP Rating: |
IP20 |
| Certification: |
RoHS |
| Voltage: |
220V |
| Light Source: |
HMI 575W Short Arc |
Product Description
Moving head spot 575 disco light
Voltage: AC210/220/230V 50/60Hz;
Rated power: 750W;
Lamp source: HMI 575W short arc;
Color temperature: Linear adjusting color temperature 3200k-5600k;
Color wheel: 2 color wheels with 14 inner color filters plus white and high speed single direction rainbow effect with adjusting speed;
Gobo wheel: 2 gobos wheels with 4 changeable roating gobos + 5 fixed gobos;
Roating gobos: 2 glass gobos wheels+ 2 metal gobos can make single gobo movement;
Fixed gobos: Up-down shaking function and single direction flowing movement effect with adjusting speed;
Prism wheel: 3-facets prism can rotated at variable speed;
Focus: Electric focusing by remote control;
Strobe: Strobe in 1-10 flashs per second;
Dimmer: 0~100% mechanical linear dimmer with full shading and full lighting effect;
Head movement: 540° Pan / 270° Tilt with 8 or 16 bit high precision scanning range with auoto position correction and variable speed; Pan movement has cut beam function which can make point projection specil effect;
Control: DMX512 signal control;
Channel: 16 channels;
Cooling system: 2 strong fans + temperature overheat protection function;
Display: LED English or Chinese display;
Material: Aluminum alloy and heat resistance plastic, IP20;
Dimension: 528*450*805mm(Carton);
Package size: 860*600*930mm (Double flycase);
Gross weight: 36KG
| Channel | Function |
| CH1 | Iris |
| CH2 | Color1 |
| CH3 | Color2 |
| CH4 | Strobe |
| CH5 | Pan |
| CH6 | Tilt |
| CH7 | Pan fine |
| CH8 | Tilt fine |
| CH9 | Pan/Tilt speed |
| CH10 | Replaceable gobos |
| CH11 | Rotating gobos |
| CH12 | Gobo rotating |
| CH13 | Focusing |
| CH14 | Prism |
| CH15 | Prism rotating |
| CH16 | Reset |
