Pixel Composing:
DIP346 1r1g1b
Module Size(W*H):
160*160 Mm
Cabinet Size (W*H*D):
1280*960*150 Mm
Cabinet Pixel:
128*96=12288
Cabinet Weight:
53 Kg
View Angle (V/H):
50° (V)/110° (H)
Driving Way:
1/4 Constant Driving
Display Type:
LED Video Display
Tube Chip Color:
Full Color
IP Rating:
IP65
Pixel Configuration:
1R, 1G, 1B
Certification:
CCC
Pixel Pitch:
10mm
Display Function:
Video Display
Application:
Stage Performance
Scanning Mode:
Static Scan
Pixel Density:
10000 dot / m²
Average Power Consumption:
350W / m²
Product Description
1. High Brightness 2. Energy Saving 3. Water Proof: IP65 4. Certificate: CE, RoHS, CCC, FCC, ETL
No.
Item
Parameter
1
Pixel Pitch
10 mm
2
Pixel Composing
DIP346 1R1G1B
3
Module Size(W*H)
160*160 mm
4
Pixel Density (Dots/m² )
10000
5
Cabinet Size (W*H*D)
1280*960*150 mm
6
Cabinet Pixel
128*96=12288
7
Cabinet Weight
53 Kg/m²
8
View Angle (V/H)
50° (V)/110° (H)
9
Brightness (Cd/m² )
≥ 5000
10
Driving Way
1/4 Constant Driving
11
Control Way
Real Pixel
12
Maximum Power Consumption
750 w/m²
13
Average Power Consumption
400 w/m²
14
Frame Frequency
≥ 60 Hz/s
15
Refresh Rate
≥ 400 Hz/s
16
Working Voltage
AC 220± 10% 50Hz or AC 110± 10% 60Hz
17
IP Rate
Front/ Rear: IP65/IP54
18
Operating Temperature
-30° C~+50° C
19
Grey Scale/Color
Displaying colors ≥ 68.7 billion (36 Bit)
20
Brightness Adjustment
256 levels per single color (manually), 8 levels per single color (automatically)
21
Input Singal Format
RF, S-Video, RGB, RGBHV, YUV, YC & Composite, etc
22
Life Span
> 100, 000 Hours
23
MTBF
> 10, 000 Hours
24
Defective Dot Rate
< 0.0001
Xinhongxiang Optoelectronics (Shenzhen) Co., Ltd. As one of the most leading LED Products manufacturer in Shenzhen China, covering 10 000 square meters, register capital high up to 30 million CNY, is one high-tech enterprise focus on researching, producing, sale and service of LED products, . Nowadays Xinhongxiang owns fully automatic production lines, independent purifying workshop, researching center, most advanced production and inspection equipments, which guarantee the quality of the LED products. All the products have exported more than 100 countries, such as USA, Mexico, Canada, Brazil, Chile, Argentina, Panama, Colombia, Germany, France, Sweden, Italy, Spain, Russia, Poland, Turkey, Ukraine, South Africa, Egypt, Saudi Arabia, Singapore, Thailand, India etc
Developing History:
From 1996 to 2010, Xinhongxiang Optoelectronics (shenzhen) Co., Ltd, mainly involved in LED encapsulation and LED Display.
Since 2010, owe to enlarge the company scale and build up self-owned brand, Xinhongxiang focus on LED lighting, Shenzhen BESDLED Co., Ltd focus on LED display, business involved in indoor and outdoor LED Encapsulation, LED Display and LED Lighting Products.
LED Display:
Full Color Indoor and outdoor LED Display, single or dual basic color LED signs, LED Curtain, LED Dance Floor, Rental LED Display,
LED Lighting:
LED Bulb, LED Tube, LED Spotlight, LED DownLight, LED Panel Light, LED Street etc,
Comparing with many of LED Manufactures, xinhongxiang owns the following advantages to be your best choice for long term cooperation partner.
1, Fully automatic production lines
Xinhongxiang owns the entire LED manufacturing line, from original Semiconductor to LED chip, then assemble to LED display and LED lighting products.
2, Advanced production equipment
SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP LED, Spectrum and Color Separation Machine, LED oven, Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and humidity programmable tester, luminance meter etc. Are equipped for our LED Product production.
3, Many Certification approved to clear up the trade barriers
CE, FCC, UL, RoHS, CCC, ISO9001: 2000 etc are obtained.
4, Strong R&D Team
Xinghongxiang absorb many talents, with more than 500 staffs, and including more than 100 engineers and technician, which paves the way for R&D for new products and excellent sales service
5): After-Service,
Principles: Response in time, solve problem ASAP and ensure the use.
Period: During warranty period, free of all maintenance charges;
