| Prod Model: |
CL-P16-RGB |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: |
320mmx160mm |
| Module Weight: |
0.55kg |
| Life Span: |
100000hour |
| Mtbf: |
10000hours |
| Warranty: |
2 Years |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
1R, 1G, 1B |
| Pixel Pitch: |
16mm |
| Display Function: |
Video Display |
| Scanning Mode: |
1/4 Scan |
| Average Power Consumption: |
350W / m² |
| Certification: |
CE, RoHS, UL, ETL |
| Pixel Density: |
3906dots/Sqm |
Product Description
P16 Outdoor Wall Advertising LED DisplayFeatures of the product:
Model No.: SM-P16mm
Pixel Configuration: 1R, 1G, 1B
Pixel Pitch: 16mm
Pixel Density: 10000 DOT / m²
Protection Level: IP65
Tube Chip Color: Full Color
Display Function: Video Display
Scanning Mode: 1/4 Scan
Average Power Consumption: 350W / m²
Certification: CE
Certificate: CE; FCC; CCC; RoHS; UL
Export Markets: Global
P16 outdoor full color LED display is specially designed for the outdoor HD shows; LED lamp adopts standard φ 4 oval DIP technology with high brightness and good heat dissipation. Every pixel is composed by red, green, blue color, the colors of the display can be reached 1.07 billion kinds, and can display colorful dynamic and static images in real time, it has perfect display effect. The display supports the usual VGA and DVI traditional video signal, it also specially supports HDMI video signal, and so on, in addition, it can receive and show video programs, such as TV programs\VCD or DVD\live programs, and so on.
P16 outdoor full color LED display adopts full automatic production, The product has high reliability, saturated and uniform color, high brightness, low consumption, long service life, is widely used in outdoor sites, such as square, outdoor concerts, theme park, shopping mall, golf courses, and so on.
|
number |
Item name |
Parameter and index |
|
unit module |
|
1 |
LED encapsulation mode |
φ 4oval DIP |
|
2 |
Horizontal axis |
120° |
|
3 |
Vertical axis |
60° |
|
4 |
Pixel composition |
1R1G1B |
|
5 |
Pixel pitch |
16mm |
|
6 |
Scan method |
1/4 |
|
7 |
Drive method |
Constant current |
|
8 |
Module resolution |
16× 8 pixels |
|
9 |
Module dimensions |
256mm× 128mm |
|
10 |
Module type |
incorporated lamp and drive |
|
11 |
Module working voltage |
+5V |
|
12 |
Module average power |
5W |
|
13 |
Module maximum power |
20W |
|
14 |
Module shell material |
PC |
|
unit cabinet |
|
1 |
Module layout |
4× 6 pieces |
|
2 |
Cabinet resolution |
64× 48 pixels |
|
3 |
Cabinet maximum power |
600W |
|
4 |
Cabinet average power |
150W |
|
5 |
Cabinet dimension |
1024mm× 768mm |
|
6 |
Cabinet material |
steel/aluminum alloy |
|
7 |
Cabinet color |
black/gray |
|
8 |
Protection grade (front/back) |
IP65/IP54 |
|
Entire screen |
|
1 |
Application environment |
outdoor |
|
2 |
Brightness |
> 8000 mcd |
|
3 |
White balance coordinates |
X=0.29, Y=0.31 |
|
4 |
contrast |
64000: 1 |
|
5 |
Color temperature |
8000K |
|
6 |
Pixel density (pixels/m² ) |
3906 |
|
7 |
Average consumption (W/m² ) |
191 |
|
8 |
Maximum consumption (W/m² ) |
763 |
|
9 |
Power source |
AC220V/50HZ or AC110V/60HZ |
|
10 |
Operating temperature |
-20º C ~ +50º C |
|
11 |
Operating humidity |
10% - 90% |
|
12 |
Storage humidity |
-30º C~ +50º C |
|
13 |
Refresh frame rate |
60Hz |
|
14 |
Refresh rate |
480Hz |
|
15 |
Viewing distance |
15-300m |
|
16 |
grayscale/color |
16.7M |
|
17 |
Brightness adjustment |
100 manual levels /100 auto levels |
|
18 |
Control method |
synchronous with the computer display |
|
19 |
Data transfer range |
Network c able: 100m |
|
20 |
Computer operating system |
WINDOWS (98, 2000, XP, Vista, 7) |
|
21 |
Video signal |
VGA, DVI, RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION and so on. |
|
22 |
MTBF |
≥ 10000 hours |
|
23 |
Longevity |
≥ 70000 hours |
Channel Cailiang (Zhangzhou) Optoelectronic Co., Ltd. is one of the biggest LED manufacture in China. Our factory have 30 PCS production line for Outdoor DIP Modules, 5 PCS line for Indoor SMD products and more than 1, 500 skilled workers. Our R&D team are comprised of a crew of 10% of total staff and most of engineers have more than 5 years experience in LED industry, which great support our new products developing or customized products according to customers' requests.
Our Main Business is Produce various LED Display Module and LED Display Panel for Customers' assemble. It' s avaliable supply all the components for assemble LED Display or LED Message Signs. Besides, we focus on offering whole proposal for LED Display Projects and Solutions. Not only for regualr type, we have continuously developed several Profiled Screens and achieved some proud success in developing Traffic Wireless Solution Display Screens.
In order to design and develop higher quality products, our R&D team always tries best to meet the US&Euro-standards for Electronic products, as well as to fulfill the special requirements from customers. Our products have been approved the German TUV- EMC Certification and Euro EN12966 Certification, and we have also achieved ISO9001: 2000, CCC, CE, FCC, RoHS Certifications.
with perfect designed products, integrated solution including both hardware and software, and superior product and service guarantee, Cailiang has been highly praised by domestic and overseas customers. We have been shipping qualified products and services to more than 50 countries and regions all over the world, such as in the USA, Japan, Russia, Sweden, Turkey, Poland, France, Israel, Argentina, Spain, Italy, etc.
We value the power of cooperative team work, we take "Quality & Honesty" as our belief, and "Being the Largest Global Supplier of LED display Solution" as our goal.
"Channel Cailiang" Sincererly Invite your participation!
