Prod Model: |
KXZ-PL00350 |
Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Size: |
D84*H22mm |
Lumen: |
210lm |
CT: |
3000k/4000k/6000k |
CRI: |
74 |
Cover: |
PMMA |
Body: |
Aluminum |
Lifespan: |
>50,000 Hours |
Hold: |
65mm |
LED Chip: |
4014 |
Body Material: |
Die-Cast Aluminum |
Light Source: |
LED |
Appearance: |
Round |
Type: |
Embedded |
Emitting Color: |
White |
Certification: |
CCC |
Housing Material: |
Acrylic |
Base Material: |
Metal |
Voltage: |
85V-265V |
Dimmable: |
Without Dimmable |
Beam Angle: |
114 |
Product Description
1. Body
Ultra-thin and screwless design, use high quality die-cast aluminum, the thickness is only 22mm, easy to install.
2. Mask
Imported acrylic light guide plate, rate of light transmission is up to 85%, well distributed and soft light.
3. Polarizer
Imported reflective material, well distribution for light, 100%no dark shadow, stable performance, very low optical loss.
4. SMD high brightness led
High luminous efficiency, lower heating value, long lifespan.
5. Integrated grid radiator
By high quality die-cast aluminum, material toughness and cooling effect is much better than ordinary aluminum.
Model No. |
Description |
Power |
Light Source |
Lumen |
CRI |
Model Size(mm) |
Cut hole(mm) |
Voltage |
Color Temp. |
Material |
Warranty |
KXZ-PL00360 |
New design Screwless Round Panel light |
3W |
SMD4014 |
210 |
74 |
Φ84*H22 |
Φ65 |
AC85-265V/50-60Hz |
Warm White
Neutral White
Cool White |
Alu |
2 Years |
KXZ-PL00660 |
6W |
420 |
Φ119*H22 |
Φ100 |
KXZ-PL00960 |
9W |
670 |
Φ149*H22 |
Φ125 |
KXZ-PL01260 |
12W |
900 |
Φ169*H22 |
Φ140 |
KXZ-PL01560 |
15W |
1170 |
Φ199*H22 |
Φ170 |
KXZ-PL01860 |
18W |
1440 |
Φ224*H22 |
Φ200 |
KXZ-PL02260 |
22W |
1650 |
Φ224*H22 |
Φ200 |
