| Prod Model: |
UP-PL5403 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| LED: |
Edison 3W LED |
| LED Qty: |
54LEDs (12r +14G +14b +14W) |
| Average Life: |
50000~100000 Hours |
| Projection Distance: |
30m |
| Color System: |
RGBW Color Mixing System |
| Waterproof: |
Waterproof |
| Shell Material: |
Aluminium Alloy |
| Electric Current Type: |
AC |
| IP Rating: |
IP66 |
| Life: |
80000h |
| Emitting Color: |
RGB |
| Certification: |
RoHS |
| Power: |
3W |
| Type: |
PAR54 |
| Input Voltage: |
110~220 |
| LED Chips: |
Edison |
Product Description
Waterproof IP66 54*3W LED PAR can
(Item#: UP-PL5403)
Tech Spec:
Input voltage: AC100~240V 50~60Hz
Power: 170W
Light source: Power 3watt
Quantity 54PCS Edison LED chip(12R+14G+14B+14W)
Rated life 80000~100000 hours
High luminous efficiency, no radiation, low power consumption, no flicker
Color: RGBW linear color mixing, build-in multi-function
Lens angle: 150 standard (80, 250, 300, 450, 600 optional)
Dimmer: 0~100% linear dimmer
Strobe: Electronic strobe, Multi strobe, Sift blending
Control mode: International standard DMX512 signal, 3-pin connect
4 channels simple mode, 8 channels standard
DMX512 signal / master-slave / sound control, DMX address optional
Self-programming mode, Self-running mode, External control mode
Other function: IP address code extension, DMX address code extension, Build-in program
Environment temperature: -200 C ~400 C
Waterproof rating: Casting Aluminum shell, IP66
Display: LED display
Dimension: 290*235*235mm
Carton Size: 300*300*380mm
Net weight: 8 kg
|
Channel |
function |
|
Ch 1 |
Lamp on |
|
Ch 2 |
RED |
|
Ch 3 |
GREEN |
|
Ch 4 |
BLUE |
|
Ch 5 |
White |
|
Ch 6 |
Flashing |
|
Ch 7 |
RGB Macro speed function |
|
Ch 8 |
RGB Macro function |
