Prod Model: |
BESD-PH16-LDY55 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Module Resolution: |
32dotsx32dots |
Module Size: |
320mmx320mm |
View Angle: |
Horizontal 110° Vertical 75° |
Best View Distance: |
>9m |
Protective Grade: |
IP65 |
Controlling System: |
Linsn |
Tube Chip Color: |
Full Color |
IP Rating: |
IP65 |
Pixel Pitch: |
10mm |
Pixel Configuration: |
1R, 1G, 1B |
Display Function: |
Video Display |
Average Power Consumption: |
350W / m² |
Pixel Density: |
10000 dot / m² |
Scanning Mode: |
Static Scan |
Display Type: |
LED Video Display |
Application: |
Advertising |
Certification: |
CCC |
Product Description
Good quality outdoor large p16 led display for advertising
Parameters and the quotation is for reference only, the latest quotation and the parameter, please contact us
Main Features |
Best View distance | Brightness | Lifespan | Warranty | Protection level |
>1m | >2000nits | >100,000hours | 2 years | IP43 |
Dot Pitch(mm) | 16mm |
Module Size(W×H) | 320mmX320mm |
Pixel Configuration | 1R1G1B |
Module Resolution(W×H) | 20 dots × 20dots |
Module pixels | 400dots |
Cabinet |
| 1. Power Modules |
2. Fans |
3. External Power cables & connectors |
4. Mounting/locking plates between cabinets |
5. Inter-connecting cables & ribbons (both power and signal) |
Cabinet Size(WxH) | 640 × 640mm |
Cabinet resolution | 32dots ×32dots |
Cabinet pixels | 1024dots |
Viewing angle | 140°/140° |
Protective Grade | IP43 |
Average Power consumption | 400 Watt/m² |
Max Power consumption | 850 Watt/m² |
Best View distance | >5M |
Weight(kg/pc) | 30kg/pc |
Material | Steel |
Control System |
Computer | Intel P4 1.5GHz, 80G HDD, 512 mb RAM or better |
Operating System | Win 98/2000/XP/NT/Vista/Win7 (PC not included in quotation) |
Software | LINSN LED Studio |
Computer Display Mode | 800×600;1024×768 or more |
Control Mode | Synchronous Control |
Sending Card | LINSN901 |
Receiving Card | LINSNRV901 |
Between Sending & Receiving Card |
Distance | Ethernet Cable | <100m |
Fiber Optic (required Media Converter) |
Multi-mode | <500m |
Mono-mode | <20Km |
Package |
Packing | Plywood box or Flight case |
Training |
Factory/On Site | Training on installation, operation on the LED Display and software |
Document |
Document | Installation Manual |
LED Studio Installation, setup, operation Manual |
Support Frame/structure for LED Display guideline |
Safety/Precaution Manual |
Training Manaul |
Notes |
1.Valid period: 1month from the issue |
2.Payment term: 40%T/T(or west union) do as deposit, 60% the balance should be paid before shipping |
3.Shipment: Within 20 days after get deposit |
4. Price: EXW ShenZhen |
Company profiles |
1. SHENZHEN BESDLED CO.,LTD is LED products manufacturer, build in 1996, cover 20,000 m². |
2. Fully automatic production lines, Advanced production equipment, Strong R&D Team. |
3. Products have exported more than 100 countries, Such as Brazil,USA,Mexico,Canada,Ukrain,Germany etc. |
4. Service before sale: technical support, design schemes; Training after order:software,operate,maintain. |
5. Certificate: SASO,CE,FCC,UL,RoHS,CCC,ISO etc. |
Our service goal |
What you think is what we need to do! |
What we promise is what we are fulfilling! |
Advanced Equipment |
Developing History: SHENZHEN BESDLED CO.,LTD
From 1996 to 2010, SHENZHEN BESD LED CO.,LTD.
Previous name Xinhongxiang Optoelectronics (shenzhen) Co.,Ltd, mainly involved in LED encapsulation and
LED Display.,led lamps , led lights .
Since 2010, owe to enlarge the company scale and build up self-owned brand, Rename to Shenzhen BESDLED Co.,LTD, business involved in indoor and
outdoor LED Encapsulation, LED Display and
LED Lighting Products.Comparing with many of LED Manufactures, BESDLED owns the following
advantages to be your best choice for long term cooperation partner.
1, Fully automatic production lines
BESDLED owns the entire LED manufacturing line, encapsulate original Semiconductor
to LED chip, then assemble to led displayand led lighting products.
2, Advanced production equipment
SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP led,
Spectrum and Color Separation Machine,
LED oven,Wave solder, Reflow soldering, Spectrum electronic and color tester,
temperature and humidity programmable tester, luminance meter etc. are equipped for our LED Product production.
3, Many Certification approved to clear up the trade barriers
CE, FCC, UL, RoHS, CCC,ISO9001:2000 etc are obtained.
4,Strong R&D Team
BESDLED absorbs many talents, with more than 500 staffs, and including more than 100 engineers and technician,
which paves the way for R&D for new products and excellent sales service
1)Training after order
After the order is placed, a processional training will be offered, including software use, operate safety, maintain equipment
2) Installation and debugging
BESD could send professionals to conduct on site installation and debugging in strict accordance with the requirements of the schemes and original manual.
3) Warranty
Warranty: 2 years warranty, lifetime maintenance
Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.
4) Maintenance
Maintenance principles: response in time, solve problems asap and ensure the use.
Maintenance period: In the maintenance period of the led display body, free of all maintenance charges.
After maintenance period, only charge the material cost and labor cost.
FAQ
1. How can i place an order?Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.
For designing or further discussion, it is better to contact us with Skype/email /phone, incase of any delays.
2. What kind of display we provide?
We have indoor/outdoor/led curtain/mobile LED /rental LED display
/LED stage/LED DanceFloor/Irregular LED display for you choose.
3. What about the lead time for order ?
Always: 3-20 days, as your order quantity, Sometimes we have stock, can delivery within 3 days
4.How about the warranty ?
We have 2years warranty and lifelong maintenance
5. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.
Warmly welcome you contact us right now or visit our factory.
Xinhongxiang Optoelectronics (Shenzhen) Co., Ltd. As one of the most leading LED Products manufacturer in Shenzhen China, covering 10 000 square meters, register capital high up to 30 million CNY, is one high-tech enterprise focus on researching, producing, sale and service of LED products, . Nowadays Xinhongxiang owns fully automatic production lines, independent purifying workshop, researching center, most advanced production and inspection equipments, which guarantee the quality of the LED products. All the products have exported more than 100 countries, such as USA, Mexico, Canada, Brazil, Chile, Argentina, Panama, Colombia, Germany, France, Sweden, Italy, Spain, Russia, Poland, Turkey, Ukraine, South Africa, Egypt, Saudi Arabia, Singapore, Thailand, India etc
Developing History:
From 1996 to 2010, Xinhongxiang Optoelectronics (shenzhen) Co., Ltd, mainly involved in LED encapsulation and LED Display.
Since 2010, owe to enlarge the company scale and build up self-owned brand, Xinhongxiang focus on LED lighting, Shenzhen BESDLED Co., Ltd focus on LED display, business involved in indoor and outdoor LED Encapsulation, LED Display and LED Lighting Products.
LED Display:
Full Color Indoor and outdoor LED Display, single or dual basic color LED signs, LED Curtain, LED Dance Floor, Rental LED Display,
LED Lighting:
LED Bulb, LED Tube, LED Spotlight, LED DownLight, LED Panel Light, LED Street etc,
Comparing with many of LED Manufactures, xinhongxiang owns the following advantages to be your best choice for long term cooperation partner.
1, Fully automatic production lines
Xinhongxiang owns the entire LED manufacturing line, from original Semiconductor to LED chip, then assemble to LED display and LED lighting products.
2, Advanced production equipment
SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP LED, Spectrum and Color Separation Machine, LED oven, Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and humidity programmable tester, luminance meter etc. Are equipped for our LED Product production.
3, Many Certification approved to clear up the trade barriers
CE, FCC, UL, RoHS, CCC, ISO9001: 2000 etc are obtained.
4, Strong R&D Team
Xinghongxiang absorb many talents, with more than 500 staffs, and including more than 100 engineers and technician, which paves the way for R&D for new products and excellent sales service
5): After-Service,
Principles: Response in time, solve problem ASAP and ensure the use.
Period: During warranty period, free of all maintenance charges;
After Warranty, only charge the material cost.
All the life time, Technology support is free.
