Features: 1. Using light emitting from sides way and guide light plate, making light effective and harmogeneous 2. Proprietary design for excellent thermal management with aluminum housing 3. Special setting of radiator installed in back part reduces the lamp's surface temperature and lengthen its lifetime 4. 70%-80% energy saving compare with tranditional lights 5. Instant soft start, No flickering, No RF interference, No UV radiation 6. Easy installation and maintenance-free
Advantages: 1. The higher luminous efficiency and lower light fades. Extraordinary Lightness; 2. Stable quality transformer, over voltage/current protection; 3. Good before and after sales service; 4. High uniformity, pure color rendering and color quality for better Visibility. 5. Attractive appearance with crystal cover and aluminum material.
Model
Normal Power
LED Chip Brand
Beam angle
Voltage
Color Temperature
Size
XHX-D30B-6WF-A1
6W
Epistar
>150°
AC85-265V
3000K/5000K/6500K
D125X75mm
XHX-D35B-8WF-A1
8W
Epistar
>150°
AC85-265V
3000K/5000K/6500K
D125X80mm
XHX-D40B-10WF-A1
10W
Epistar
>150°
AC85-265V
3000K/5000K/6500K
D140X80mm
XHX-D50B-15WF-A1
15W
Epistar
>150°
AC85-265V
3000K/5000K/6500K
D180X80 mm
XHX-D60B-20WF-A1
20W
Epistar
>150°
AC85-265V
3000K/5000K/6500K
D190X80 mm
XHX-D80B-24WF-A1
24W
Epistar
>150°
AC85-265V
3000K/5000K/6500K
D190X80 mm
XHX-D80B-30WF-A2
30W
Epistar
>150°
AC85-265V
3000K/5000K/6500K
D190X80 mm
Application: 1). Business malls 2). Home such as kitchens 3). Bathrooms 4). Balconies 5). Corridors 6). Bedrooms 7). Living rooms 8). Book houses, etc
Parameter
Symbol
Remark
Min
Typ.
Max.
Uint
Power Consuption
P
-
20
W
Input Voltage
Vin
50/60Hz
110/230
V
Input Current
lin
-
100/150
mA
Power Factor
Φ
Φ =P/S
-
> 0.9
-
-
Operating Temperature
T
-20
25
40
° C
Storage Temperature
T
-
-30
25
55
° C
Lumen Output(WW)
lm
XHX-TD06-14W
-
1200
-
lm
Lumen Output(CW)
lm
XHX-TD06-14C
-
1200
-
Lm
Color Temperature(WW)
CCT
XHX-TD06-14W
-
3000
-
K
Color Temperature(CW)
CCT
XHX-TD06-14C
-
6500
-
K
Color Rendering Index
CRI
XHX-TD06-14W
75
Percent
Dimming Range
-
Optional
0
-
100
Percent
Xinhongxiang Optoelectronics (Shenzhen) Co., Ltd. As one of the most leading LED Products manufacturer in Shenzhen China, covering 10 000 square meters, register capital high up to 30 million CNY, is one high-tech enterprise focus on researching, producing, sale and service of LED products, . Nowadays Xinhongxiang owns fully automatic production lines, independent purifying workshop, researching center, most advanced production and inspection equipments, which guarantee the quality of the LED products. All the products have exported more than 100 countries, such as USA, Mexico, Canada, Brazil, Chile, Argentina, Panama, Colombia, Germany, France, Sweden, Italy, Spain, Russia, Poland, Turkey, Ukraine, South Africa, Egypt, Saudi Arabia, Singapore, Thailand, India etc
Developing History:
From 1996 to 2010, Xinhongxiang Optoelectronics (shenzhen) Co., Ltd, mainly involved in LED encapsulation and LED Display.
Since 2010, owe to enlarge the company scale and build up self-owned brand, Xinhongxiang focus on LED lighting, Shenzhen BESDLED Co., Ltd focus on LED display, business involved in indoor and outdoor LED Encapsulation, LED Display and LED Lighting Products.
LED Display:
Full Color Indoor and outdoor LED Display, single or dual basic color LED signs, LED Curtain, LED Dance Floor, Rental LED Display,
LED Lighting:
LED Bulb, LED Tube, LED Spotlight, LED DownLight, LED Panel Light, LED Street etc,
Comparing with many of LED Manufactures, xinhongxiang owns the following advantages to be your best choice for long term cooperation partner.
1, Fully automatic production lines
Xinhongxiang owns the entire LED manufacturing line, from original Semiconductor to LED chip, then assemble to LED display and LED lighting products.
2, Advanced production equipment
SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP LED, Spectrum and Color Separation Machine, LED oven, Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and humidity programmable tester, luminance meter etc. Are equipped for our LED Product production.
3, Many Certification approved to clear up the trade barriers
CE, FCC, UL, RoHS, CCC, ISO9001: 2000 etc are obtained.
4, Strong R&D Team
Xinghongxiang absorb many talents, with more than 500 staffs, and including more than 100 engineers and technician, which paves the way for R&D for new products and excellent sales service
5): After-Service,
Principles: Response in time, solve problem ASAP and ensure the use.
Period: During warranty period, free of all maintenance charges;
