| Prod Model: |
G6015 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Light Source: |
LED |
| Control Channel: |
10CH or 15CH |
Product Description
Channels: 10 or 15 DMX channels
Pan: 540°
Tilt: 270°
Color wheel: 7 colors+white
Rainbow effect
Gobo Wheel 1: 8 Static gobo+open+Rainbow effect
Gobo Wheel 2: 6 gobo+open 5 metal, 1 glass installed
Rainbow effect+Gobo shake
Prism: 3-facet prism
Shutter: Variable electronic shutter(for strobing)
Focus: Variable motorized focus
Dimmer: Variable electronic dimmer(0-100%)
User-selectable pan/tilt ranges
Pan: 540° , 360° , 180°
Tilt: 270° , 180° , 90°
User-selectable basic or advanced operating modes;
Power Supply: AC100V-240V, 50Hz/60Hz
Fitting Lamp: 60W White LED (LUMINUS CST-90)
Power consumption: 110W
Beam angle: 14°
Lux: 18000@1m
|
Channels |
|
Channel |
Function |
|
1 |
Pan |
|
2 |
Tilt |
|
3 |
Pan Fine |
|
4 |
Tilt Fine |
|
5 |
XY Speed |
|
6 |
Color |
|
7 |
Gobo Wheel |
|
8 |
Gobo Rotation |
|
9 |
fix Gobo |
|
10 |
Strobe |
|
11 |
Dimmer |
|
12 |
function |
|
13 |
Movement Macros |
|
14 |
Prism |
|
15 |
Focus |
GLM Stage Light & Sound Co., Ltd is a professional manufacturer of LED STAGE LIGHTING(moving head), eg: 60W Spot, 108W Wash, 54W Wash, 15W Spot, 30W Spot, 56W Wash, RGBW, RGB etc. All of products approved by CE and RoHS certification.
