| Prod Model: |
UP-PL5403 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Voltage: |
AC90-245V, 50/60Hz |
| LED Qty: |
54PCS*3W LEDs(R: 12, G: 14, B: 14, W: 14) |
| Light Source: |
Super Brightness Edison Lamp |
| IP Grade: |
IP64 |
| N. W: |
8kg |
| Waterproof: |
Waterproof |
| Shell Material: |
Aluminium Alloy |
| Electric Current Type: |
AC |
| IP Rating: |
IP66 |
| Life: |
80000h |
| Emitting Color: |
RGB |
| Certification: |
RoHS |
| Power: |
3W |
| Type: |
PAR 54 |
| Input Voltage: |
AC90V-250V (50/60Hz) |
| LED Chips: |
Edison |
Product Description
Hot sale 53*3w Waterproof LED wall washer light
Technical Specification:
Voltage: AC90V-250V (50/60Hz);
Rated Power: 170W;
LED lamp: Edison 3W high power LED with long life 50000-100000 hours, high luminous efficiency, no radiation and low power consumption etc;
LED Qty: 54LEDS (12red +14green +14 blue +14 white);
LED Lamp powr supply: Adopt power factor correction PFC switching power supply, PF> 0.99, the efficiency of up to 90%, it's real green and environmental protection;
LED drive mode: Adopt static constant current drive mode with high precision and non-flicker (400HZ);
Projection distance: 30M
Waterproof grade: IP66
Control Mode: DMX512 signal 3-pins connection control / master-salve control / sound control with self-programming mode, self-running mode, extral control mode;
Channel: 4ch, 8ch two channel modes;
Color: RGBW color mixing system with color rainbow and HSL color mixing adjustment which is the most favorite color mixing way for lighting technician;
Len: High optical transmission acrylic lens;
Beam angle: Standard 15 ° , and 8 ° , 25 ° , 30 ° , 45 ° , 60 ° Is optional;
Dimmer: 0~100% linear dimmer;
Strobe: Multi-function strobe effects from 1 to 25 times per second with color rainbow and can show multi-colors by
Adjusting white LED;
Material: Aluminum alloy plus plastic;
Maximum working terperature: 45° C
Maximum surface temperature: 60 ° C
Application: Lighting for TV studio, theater, opera house, auditorium, stage, T-stage, concerts, and vocal concert,
DJ effect, disco effect, club effect, party effect etc;
Dimensions: 290*235*235 (mm)
Package size: 300*300*400 (mm)
Gross weight: 9.5kg
About us
1. Our main products are moving head lights, fog machines. LED effect light and so on.
2. We can depend on customers' request to reseach develop new products.
Why choose us
1. We prefer a long-term cooperation to a short-term profit.
2. We can not ensure a perfect quality but we can do our best for the after-sale service.
3. We always reply your inquiry at the first time because we believe the efficiency is a good beginning.
|
Channel |
function |
|
Ch 1 |
Lamp on |
|
Ch 2 |
RED |
|
Ch 3 |
GREEN |
|
Ch 4 |
BLUE |
|
Ch 5 |
White |
|
Ch 6 |
Flashing |
|
Ch 7 |
RGB Macro speed function |
|
Ch 8 |
RGB Macro function |
Uplight Stage Equipment (Guangzhou) Co., Ltd. is a high-tech company, which is engaged in R&D, manufacturing and marketing of stage equipments. The main products include moving lighting, LED stage equipments, follow spot, laser light, gobo light, etc.
We own a professional R&D team, who has 10 years experience in stage lighting. Our sales team can provide best service by engineers and technical staff members' supporting. We passed the ISO9001: 2000 quality management system standard as well. There are numerous domestic projects we have been undertaken, was praised by all the customers.
To become the leading stage lighting supplier on a global basis. We view our customers as the most important element in our business, strive to exceed the customer's expectation.
