Features
ø Output power: 15W
ø LED type: COB 15W
ø LED quantity: 1PCS
ø Luminous intensity: 932.2LM
ø Beam angle: 78°
ø Maximum size: D*H=138*83MM
ø Net weight: 636g
ø Housing material: Aluminum alloy+PC
ø Lifespan: >30000H
Application
Suitable for family, hotel, restaurant, hall, pub, casino, show business, lighting, marketplace, meeting room and exhibition
Caution
1. Suitable for indoor application. Do not use this product on outdoor or humid environment.
2. -20 to 40 ° C operation temperature. -30 to 60 ° C storage temperature. Use and store lamps under related temperature.
3. Clean the lamp surface regularly with dry cloth If the environment has dust pollution.
4. Contact supplier within warranty period if there are any failure problems. Do not disassemble
Product without permission. Otherwise no warranty.
After-sales service
All products are guaranteed to use in one year. Under the Right and normal using condition, quality warranty is based On correct conservation, assemblage, and maintenance. As Incorrect usage, and disobeying product operation, it's not Guaranteed. To the problem within promised time, "Aglare" Will solve it by repair, substitute accessories or replacement For your option. Upon exceeding the promised time, there Will be material and maintenance fees to be paid by customer.
|
Type |
input voltage |
PF |
Output wattage |
Output Luminous Flux |
beam angle
|
product size
(MM) |
Recommended opening size(MM) |
Net weight(including driver) |
|
YJ-DLB90-IW1X5 |
AC90-260V |
0.9 |
5W |
311.17LM |
78 ° |
D *H=90*59 |
D =63 |
200.5g |
|
YJ-DLB109-IW1X10 |
AC90-260V |
0.9 |
10W |
600.23LM |
78 ° |
D *H=109*78 |
D =90 |
364g |
|
YJ-DLB138-IW1X15 |
AC90-260V |
0.9 |
15W |
923.31LM |
78 ° |
D *H=138*83 |
D =116 |
636g |
