Model: ZY-B200
Technical Parameter:
| Light Source | 190W UHP Phillip 5r |
| Power Consumption | 250W |
| Control | DMX512, Master-Slave, Auto Mode |
| Color | 14 fixed colors + open |
| Gobo | 17 fixed gobos+open |
| Channel | 16 |
| Prism | 8-facet rotating prism |
| Beam Angle | 0-3.8 degree |
| Dimmer | 0-100% dimming |
| Weight | 17kg |
| Warranty | 2 years |
Lamp Source:
2 type for option: OSRAM SIRIUS HRI® 190W/UHP Phillip 5R
Color temperature: 8,000K
Average Life: 2,000Hrs
Electrical
Input Voltage: AC90-240V 50/60HZ
Power Consumption: 250W
Control
Display: 4-button LED digital display or LCD display selectable, can be turned 180°
&record the using time
Control Protocol: DMX512,automatic and master/slave mode
Channel: 16/20CH
Optical System
YL(YiLong) 3in1 optical group combination
Dimming: 0-100% linear adjustment
Strobe: 0-15t/s
Focus: ELectronic
Prism: Rotating 8-facet prism
Frost filter
Beam angle:0-3.8 degree
Movement
Pan:540°
TilL:270°
Pan/Tilt Resolution: 16bit
Gobos&Colors
Rotating Gobos: 1 gobos wheel with 17 fixed gobos+open
Colors: 1 color wheel with 14 fixed colors+open
Physical
Housing: Flame-retardant plastic
Housing Color: Black or White selectable
Fixture Connection: 3-Pin DMX in&out, power in
Cooling: Quiet cooling fan and aluminum radiator
Certificate&Satety
Certificate: CE
Working environment: Indoor
Operation temp:-20~40ºC
Packing
Accessories: Standard power cable, signal cable and omega
Optional safety cable and clamps
Product Size: 335*305*475mm
Carton Size: 410*440*540mm
Dula case:850*480*710mm
N.W.:17.00KGs
G W.:19.5KGs
Packing: Carton or flight case
Trade terms
| MOQ | 1 pcs |
| Price term | FOB / EXW / CIF |
| Payment terms | T/T , Western union , Cash |
| Package | Carton box / Flight case |
| Delivery time | For sample order: about 3 - 5days after payment
For big order : about 5-15days after payment |
| Shipping | By air ,
By sea ;
By express : DHL / UPS / Fedex/EMS |
| OEM | We accept OEM order |
| Warranty | Two years |
| After sells service |
If there is the problem with the product, firstly you need send the picture or the video to us,
then let us make sure what's problem about the product, we will try our best to help you .
if the problem can use the part to solve ,we will offer you the replacement for free Within 1 year.
|
Company Information
Guangzhou CN Eagle Lighting Co., Ltd. is a hightech company, which is engaged in R&D, manufacturing
and marketing of stage equipment.
Our main products include 330W/ 230W/ 200W moving head beam, 36 * 10W /19 * 12W LED Moving
Head Zoom, 19 * 15W/ 6 * 12W LED Bee EYE Moving Head, 18 * 10W/ 54 * 3W LED PAR Lights etc.
We own a professional R&D team, who has 10 more years experience in stage lighting. Our sales team
can provide best service by engineers and technical staff members' supporting. We passed CE quality
management system standard as well. There are numerous domestic projects we have been undertaken
, was praised by all the customers.
Customer First! We always strive to exceed the customer's expectation. Let us go together to become the
leading stage lighting supplier on a global market
Guangzhou CN Eagle Lighting Co., Ltd. is a high-tech company, which is engaged in R&D, manufacturing and marketing of stage equipments.
The main products include moving head beam, LED stage light, follow spot, LED PAR Lights etc.
We own a professional R&D team, who has about 10 more years experience in stage lighting.
Our sales team can provide best service by engineers and technical staff members' supporting.
Most of our products have passed CE quality management system standard as well.
There are numerous domestic projects we have been undertaken, was praised by all the customers.
Our main products are 200W/230W/280W/330W 5r/7r/10r/15r moving head beam, 19 X 15W bee eye LED moving head, 36/37 X 15W LED moving head, 54 X 3W LED PAR/ non-waterproof LED PAR,
8 X 12W LED moving spider light etc,
Our lighting are suitable for stage event, concert, studio, night club, disco, architectural, karaoke television we currently provide comprehensive service and customer support to over 40 international countries and regions.
We offer high quality products, best after-sales service, fast shipment.
Customer First! We always strive to exceed the customer's expectation. We go thogether to become the leading stage lighting supplier on a global maket.
