Stage COB PAR/LED with 200W Wide Floor Light RGBWU 5 in 1
- Using high MCD COB LED(chip on board) to achieve much more brightness and excellent ventilations and lowest energy consumption,
- With surface light source function plus the molded polishing/mirror finish reflector, specially designed frost plano-convex lens, making light projections perfectly focused,
- The brightness more than two times as much as previously done, covering far distance.
- Really ideal for lighting stages, BARS, DISCO HALLS, SMALL SHOWS, CABARETS, MUSIC SHOPS, MOBILE DJs, etc.
Equipped with 200W RGBWU five in one COB high MCD LED
4 operational modes: DMX, Master/Slave, Stand Alone & Sound Active
8 sub menus with serial numbers for easy operations
Fans running speeds adjustable by the programming for less noise
Beam angle 24 degrees, field angle 44 degrees
5/7/10 DMX channel modes
Blue LCD display
Du hanging bracket included, 3-pin XLR In/Out
Shutter: Pulse effect; Random strobe slow to fast
Power Consumption: 230W max
Dimensions (LxWxH): 45*24*18cm/hanging brackets placed vertically
Weight: 4.10kgs
DMX FUNCTIONS: 5-CHANNEL MODE.
Channel 1 red from darkness to full brightness.
Channel 2 green from darkness to full brightness.
Channel 3 blue from darkness to full brightness.
Channel 4 white from darkness to full brightness.
Channel 5 UV from darkness to full brightness.
DMX FUNCTIONS: 7-CHANNEL MODE.
Channel 1 red from darkness to full brightness.
Channel 2 green from darkness to full brightness.
Channel 3 blue from darkness to full brightness.
Channel 4 white from darkness to full brightness.
Channel 5 UV from darkness to full brightness.
Channel 6 dimmer from darkness to full brightness.
Channel 7 strobe.
DMX FUNCTIONS: 10-CHANNEL MODE.
Channel 1 red from darkness to full brightness.
Channel 2 green from darkness to full brightness.
Channel 3 blue from darkness to full brightness.
Channel 4 white from darkness to full brightness.
Channel 5 UV from darkness to full brightness.
Channel 6 dimmer from darkness to full brightness.
Channel 7 strobe.
Channel 8 color macros.
Channel 9 color changing from slow to fast.
Channel 10 color fade from slow to fast.Picture:
|
DISTANCE(M) |
COLOR |
BRIGHTNESS(LUX) |
BEAM ANGLE |
FIELD ANGLE |
DIAMETER OF THE COVERING AREA(ROUND:M) |
|
1 |
RGBWU |
9000 |
24° |
44° |
0.70 |
|
2 |
RGBWU |
3000 |
24° |
44° |
1.40 |
|
3 |
RGBWU |
2000 |
24° |
44° |
2.10 |
|
1 |
RED |
2000 |
24° |
44° |
0.70 |
|
2 |
RED |
900 |
24° |
44° |
1.40 |
|
3 |
RED |
500 |
24° |
44° |
2.10 |
|
1 |
GREEN |
2200 |
24° |
44° |
0.70 |
|
2 |
GREEN |
1200 |
24° |
44° |
1.40 |
|
3 |
GREEN |
700 |
24° |
44° |
2.10 |
|
1 |
BLUE |
300 |
24° |
44° |
0.70 |
|
2 |
BLUE |
150 |
24° |
44° |
1.40 |
|
3 |
BLUE |
80 |
24° |
44° |
2.10 |
|
1 |
WHITE |
3500 |
24° |
44° |
0.70 |
|
2 |
WHITE |
1000 |
24° |
44° |
1.40 |
|
3 |
WHITE |
500 |
24° |
44° |
2.10 |
|
1 |
UV |
200 |
24° |
44° |
0.70 |
|
2 |
UV |
100 |
24° |
44° |
1.40 |
|
3 |
UV |
50 |
24° |
44° |
2.10 |
