Led Solar street light
Led street light
Solar highway light
Solar street light Applications:
-Area Lighting.
-Airport Lighting.
-Hospital Parking.
-Parking Lot lighting.
-HighWay RoadWay Lighting.
-Street lighting.
-Security Light.
-Highway and ramp lighting.
-Bridge lighting, Under Pass lighting.
-Residential, Industrial, Commercial lighting.
1. LED lamp
Working Voltage DC12V/24V,
General luminous: 8000lm,
Luminous Efficiency: 100lm/W,
Center illuminance: 14lx, Ra>80,
Color temperature: 2700-7000, Protection Grade: IP65
Working life >50000, It can woke more than 10 years in accordance with 12 hours a day.
Lamp shade is Die-casting molded with aluminum alloy, and its face is UV-resistant and corrosion resistant.
No bad glare; No Strobe; Start without delay. Low maintenance cost.
2. POLE
Components surface is sprayed with the powder after hot galvanized anti-corrosion treatment, smooth surface, non-discolouring, no pinhole hang, no flow, no peeling phenomenon;
Galvanized layer thickness is not less than 85 microns, the coating thickness is not less than 100 microns.
Galvanized treatment is in accordance with the standard of GB/T13912-2002 " Film pencil hardness measurement",
GB/T1732-1993 "Paint film punching resistance measurement",
GB/T9286-1998 "Paint film of the cross test"
3. FOUNDATION AND FIXTURE
Components surface is sprayed with the powder after hot galvanized anti-corrosion treatment, smooth surface, non-discolouring, no pinhole hang, no flow, no peeling phenomenon;
Galvanized layer thickness is not less than 85 microns, the coating thickness is not less than 100 microns.
Galvanized treatment is in accordance with the standard of GB/T13912-2002 " Film pencil hardness measurement",
GB/T1732-1993 "Paint film punching resistance measurement", GB/T9286-1998 "Paint film of the cross test"
4. Solar panel
1. Grade A cells +tempering glass+EVA
2.90% output power in 10 years and 80% output power in 25 years
3. CE IEC TUV SONCAP ISO
5. Battery
Full seal and free-maintaince
6. Controller
Germany brand Phocos
IP68, time and light control
7. Wind turbine generator
300w horizontal wind turbine generator, 1.2 meter blade
8. CERTIFICATES: TUV CE IEC SUNCAP
|
Pole |
Height:2.5m-12m; material:Q235 steel;
Disposal of surface:hot galvanization and spraying powder.
Color:RAL k5 classic optional
Shape:round,square,octagonal etc. |
System voltage |
DC 12V/24V |
Light source |
LED,Saving energy, HFED, LPS |
Fixture |
IP65,Aluminum alloy die-casting form. |
PV module |
Mono or poly solar panel:80W to 370W, can be folded . |
|
Storage battery |
Deep recycle lead-acid/gel battery from 65AH to 200AH/12V |
|
Phocos Controller |
IP68 controller with remote control ,5A-20A with automatically time and light control,overcharge and overdischarge protection; |
|
Bracket |
The angle can be adjusted.
Material:Q235 steel(hot galvanizing and spraying powder) |
|
Battery box |
PVC box/ABS engineering plastics; Lead-acid / Gel battery.
Position of battery:On the pole or underground |
|
Daily service hours |
5-12hours (design according to requirement) |
|
Cloudy&rainy day |
1-9days (design according to requirement) |
Warranty |
1years |
Usage |
street,parking lot,highway,residential etc. |
|
Advantages |
Easy installation;Environment protection;Free of maintenace; Bracket angle can be adjusted; |
