Description of design
1. This system configuration is suitable for area that peak sunshine for five hours, three continuous rainy days.
System configuration can be designed according to customer's specific project requirements and climate conditions.
2. The energy of Solar street lighting is form solar radiation, Whether the sunlight that exposure to solar panels is abundant or not directly affect lamp lighting effects,
So solar panels can exposure to sunlight at any period of time, so when Select where to install the lamp, you should avoid tall buildings or other objects that can block the panels.
3. In order to ensure its beautiful characteristic and its ability that receive better solar radiation, we suggest that you should clean the dust on the solar panels every half of one year, but don't rinse area from the bottom up.
4. Battery is placed on the top of the pole, and it's good for battery heat-dissipation, shortening the length of the cable, reducing pressure drop, easy installation & anti-theft.
Product obtained CE TUV SONCAP and MCS certificate application range
---------------------------------
JoySolar
Established in 1984, specializes in developing and manufacturing customized solar powered lighting systems for a wide range of lighting applications. It currently owns its own manufacturing plants with a total area of 40, 000 square meters, with multiple workshops for the production of solar panels, lamp poles, and LED lights. The plants have an annual manufacturing capacity of 15, 000-20, 000 sets.
JoySolar Advantages
The Most Competitive Price
- As one of the leading manufacturers of solar outdoor lights, JoySolar engineering team designs the most economic solar street lights in many aspects (such as production cost, transportation cost, installation cost and maintainance cost ).
- JoySolar' solar outdoor lights with the most reasonable configurations and the best components sells solar lights at the most favorable prices in the industry.
- We pay attention to every component and work diligently to ensure that every step of the energy conversion process is maximized.
- We only use the best components so that we minimize the total cost of ownership for our customers.
JoySolar Solar Light for You
- JoySolar works with our customers to design the best street lighting solution for their individual needs.
- We customize every solar light part by part to ensure it is the optimal choice for your environment, temperature as well as sunlight duration.
- There are hundreds of light fixtures and pole designs you can choose from.
Customer Service
- JoySolar offers you excellent customer service with highly competitive prices.
- Our sales and service team in China will provide you with attentive service along with durable and dependable solar light
Solar Panel: |
1pcs*65Wp 24V, high-efficiency polycrystalline PV module |
Light Source: |
15W DC24V; LED street lamp, 110~120LM/W |
Controller: |
12V/24V 5A, light/time intelligent control, waterproof, IP68guard level; various protections |
Battery: |
2pcs*12V65AH, solar special lead-acid battery, fully sealed deep cycle free maintenance type |
Battery Box: |
Hot dip galvanized battery box |
Pole Set: |
3-6m high, Q235 steel pipe; hot-dip galvanized and spray coated treatment, rustproof; including solar panel bracket and lamp arm, foundation not included |
Working time: |
10 -12 hours/day (6hrs full power + 6hrs half power lighting mode) , battery capacity providing 2-3 continuous cloudy or rainy days backup |
