600*600mm positive lighting LED Panel Light 600*600mm
Size: 300*300mm ( 600*600mm, 300*1200mm, 300*600mm are available)
Voltage: AC85-265V
Rendering index: 80
PF: 0.95%
LM/W: 85-90
IP54
LED Color: Warm white (2700-3300K); Commericial White (4000-4500K); Cool White (5500-6000K) and other colors
Features:
1) Dimensions: 300x300mm (308PCS LED's), 300x600mm(318PCS LED's), 600x600mm (624PCS LED's), 300 x1200mm (624PCS LED's)
2) Luminous flux: 1700lm-1900lm (300x300mm, 308PCS LED's); 1700lm-1900lm (600x300mm, 318PCS LED's); 3900lm-4100lm (600x600mm, 624PCS LED's); 3900lm-4100lm (300x1200mm, 624PCS LED's)
3) Color Temperature: 5500-6000K
4) With infrared remote dimmer for dimming 0~100
5) Can be ceiling or wall surface-mounted
6) Warm White version is available too
7) Ultra-slim and low-profile
8) Can be recessed mounted, surface mounted or work as a pendant.
9) Consumes 70%~80% less energy than halogen spotlights
10) Lifespan 50, 000 hours (5 years), which is 20 x longer life than conventional bulbs
11) Extremely low maintenance costs
12) No flickering, No RF interference, No UV radiation
13) CE & RoHS compliant
14) Instant soft start
15) Proprietary design for excellent thermal management with aluminum and acrylic housing
16) Dimmable by RF remote controller
Installation Instruction:
1) Working Voltage: AC85-265V
2) wiring way: L -L, N -N
3) Usage of remote controller: A button - power swift; B button - light up; C button- light down.
Notice:
1) No pressing or striking
2) Transport and handle carefully
3) Pay attention to the voltage before using
4) Ambient temperature: 0° C-+50° C;
5) Indoor use only
6) No twisting when power is on
Application:
Commercial Lighting, Office Lighting, Warehouse Lighting, Supermarket Lighting
Applied to hotel, meeting room, factory, office, home, school, hospital, ect.
Remark:
1. All the shape, size, color, brightness is available here and OEM and ODM is welcome;
2. Goolite can design according to clients' requirement
ITEM No.
Lamp Sourse
COLOR
LUMINOUS FLUX
Power (W)
BEAM ANGLE
VOLTAGE
G.W. (kg)
Remark
BQ-PSP-3030
3528 SMD 225 pcs
cool white
1050lm
16
120°
AC85-265V
2.1±0.02
Dimmer function are available
BQ-PSP-6030
3528 SMD 450 pcs
cool white
2100lm
30
120°
AC85-265V
3.25±0.02
BQ-PSP-6060
3528 SMD 900 pcs
cool white
4700lm
58
120°
AC85-265V
4.85±0.02
BQ-PSP-60120
3528 SMD 900 pcs
cool white
9600lm
112
120°
AC85-265V
Part No.
Dimension
CCT
Detail Data
Unit Packing Size (mm)
Unit Packing Weight (g)
BQ-PBC-3030/3014
L*W*H//300*300*12.0
Warm White: 2700-3300K
308pcs 3014 LED SMD
PF: 0.95% LM/W: 85-90
Commericial White: 4000-4500K
Power (W): 20W±1W
Voltage: 85-265V
375X375X65mm
1.1Kg
Pure White: 5500-6500K
Lumin Flux: 1800±100LM
IP54
Part No.
Dimension
CCT
Detail Data
Unit Packing Size (mm)
Unit Packing Weight (g)
BQ-PBC-3060/3014
L*W*H//300*600*12.0
Warm White: 2700-3300K
312pcs 3014 LED SMD
PF: 0.95% LM/W: 85-90
Commericial White: 4000-4500K
Power (W): 20W±1W
Voltage: 85-265V
675X375X65mm
1.1Kg
Pure White: 5500-6500K
Lumin Flux: 1800±100LM
IP54
Part No.
Dimension
CCT
Detail Data
Unit Packing Size (mm)
Unit Packing Weight (g)
BQ-PBC-6060/3014
L*W*H//600*600*12.0
Warm White: 2700-3300K
624pcs 3014 LED SMD
PF: 0.95% LM/W: 85-90
Commericial White: 4000-4500K
Power (W): 45W±1W
Voltage: 85-265V
675X675X65mm
3.6Kg
Pure White: 5500-6500K
Lumin Flux: 4000±100LM
IP54
Part No.
Dimension
CCT
Detail Data
Unit Packing Size (mm)
Unit Packing Weight (g)
BQ-PBC-3012/3014
L*W*H//300*1200*12.0
Warm White: 2700-3300K
624pcs 3014 LED SMD
PF: 0.95% LM/W: 85-90
Commericial White: 4000-4500K
Power (W): 45W±1W
Voltage: 85-265V
1275X375X65mm
3.6Kg
Pure White: 5500-6500K
Lumin Flux: 4000±100LM
IP54
Shenzhen Banq Technology Co., Ltd., is a professional LED manufacturer with strong capability in R&D, Production, Marketing and customer service. We have a variety of products, which can be classified in two catagories:
First is LED general illumination lights which including LED bulb, LED tube, LED strip/Ribbon, LED spotlight, LED down light, LED SMD spotlight, Auto light, wall washer, as well as LED module. Second is indicating LED for different applications which including high/low power LED series. Super flux LED (Piranha) series, SMD LED series, and super-bright through-hole LED series. Our products are widely used in General Illumination Industry, Auto Industry, Electronic Display Industry and signal Electronic iIndustry etc.
Established in 2002, with a total area of 16000 square meters, BANQ has about 1000 well-trained employees. With our dedicated staffs and rich experience in LED field, we can quickly respond to customer needs, providing customized products and services to help customers succeed. At present, we export 90% of our prodcuts Europe, North America, and some other countries.
"Quality First, Customer Paramount, Service Uppermost! " is our principles. In order to make the life of modern people more wonderful, BANQ is willing to form a close ally with customers through our superior LED products, excellent and value-added service.
