3W LED recessed underwater light, Mini 3W LED Recessed Underwater Spotlight, Cute 3W Recessed Led Swimming Pool Spotlight, Led Spa Light, Led Pond Light, stainless steel Recessed Led Underwater spotlight,
Specification
Dimension: Φ 67.5x72.5mm for light
Φ 65x100x110mm for mounting sleeve
Waterproof Level: IP68.
LED: EPISTAR (Prolight in Taiwan), BRIDGELUX or CREE.
Optical lens, efficiency 90%.
Step tempered glass. T=8.
Power Cable: H05RN-Fx0.75² X 3m x plug(2pin for low voltage, 4pin for RGB), UL/VDE.
Specialized for fulltime underwater using, in full compliance with IP68, specification as:
1, Concise & smart design.
2, Stainless steel whole body(SUS304, 316 Optional), super corrosion resistance and Endurability.
3, Special light distribution, perfect performance Of high light-efficiency.
4, Multi-waterproof measures, high efficiency & long-life of LED light source.
5, Intensified PVC mounting sleeve with 4pcs of Sliding side-covers for power cord outlet,
Simplifying installation and enhancing Aesthetics of light system.
6, Support RGB multi-color type.
Features
1, High efficiency
2, More than 25000 hours economic working life
3, Unique & strong housing design
4, Excellent color effects
Benefit
1, Maximum economizing for electricity consumption.
2, Compared to the traditional lamps, LED light can effectively save using and maintenance cost
3, Product's reliability increased significantly
4, 16.77 million full color mixtures & changes after connected by special RGB controller
Application
1, Landscape illumination
2, Water features lighting
|
Specifications |
|
Item No. |
PR–B4C0101 |
PR–B4C0102 |
PR–B4C0106 |
PR–C4C0101 |
PR–C4C0102 |
PR-C4C0106 |
|
LED |
1x1W single color |
1x3W single color |
1x3W RGB 3in1 |
1x1W single color |
1x3W single color |
1x3W RGB 3in1 |
|
CCT |
White light 2700K\4500K\6500K\R\G\B \Amber\RGB 3in1 |
|
CRI(Ra) |
more than 75 |
|
Input Voltage |
24 VDC |
|
Frequency |
50 / 60 Hz |
|
Lens Beam Angle |
25° 30° |
Asymmetrical 35° / 50° wall-wash |
|
Consumption (w) |
1.5 |
2.8 |
3.6 |
1.5 |
2.8 |
3.6 |
|
Economy Life Time |
> 25000 hrs |
|
Operating Temp. |
0 °C ~ normal atmospheric temperature |
|
Usage |
Full-time use underwater, less than 1 meter depth. |
|
|
Must be installed underwater prevent from burning. |
|
Accessories |
PVC Mounting sleeve with stainless steel ring |
|
Water-proof Level |
IP 68 |
|
Material |
|
LED |
EPISTAR (Prolight in Taiwan), BRIDGELUX or CREE |
|
Lens |
Optical lens, efficiency higher than 90% |
|
Housing |
Stainless steel(SUS304,316 optional) |
|
Glass |
Step tempered glass. T=8mm Loading capacity: exert force area of ø10=1130kgs |
|
Cable gland |
IP68 PG-11 copper and nickel coated |
|
Power cable |
H05RN-F x 0.75 mm2 x 3m x plug(2pin for low voltage, 4pin for RGB), UL/VDE. |
|
Gasket |
EPDM gasket |
|
Package |
|
Net weight |
0.76 kg |
|
Packaging size |
24.5 x 24.5 x 25 cm (L x W x H) |
|
Qty. / Ctn. |
4 pcs / Ctn. or Customization |
|
Gross weight |
4.2 kg |
