P6 Indoor Full Color LED Display Screen Technical Parameters
Item | Parameter |
Model | P6 indoor full color LED module |
Module size | 192mm * 96mm |
Pixel pitch | 6mm |
Pixel density | 27777dots/m² |
Pixel configuration | 1R1G1B |
Module resolution | 32dots(W) * 16dots(H) |
Max power consumption | 15W |
Module thickness | 14.85mm |
Module weight | 0.154KG |
Driving method | Constant current driving |
Scan method | 1/8 scan |
Interface way | HUB75-A |
Brightness | ≥3000cd/m² |
Cabinet size | 576mm * 576mm |
Power supply mode | 5V/40A*2pcs |
Thermal discharge | Fan 2pcs |
Optimal viewing distance | 6M - 40M |
Optimal viewing angle | 160º(W) 120º(H) |
Environment temperature | -20º ~ +50º |
Relative humidity | 10% - 95% |
Operating voltage | AC220V ± 10% |
Average power | 270W/H |
Max power consumption | ≤810W/m² |
Control mode | Synchronization |
Driving device | IC constant current driving |
Refresh rate | ≥400HZ |
Gray/Color | RGB each 256 grade,can display 16.7M color |
MTBF | ≥9000hours |
Power switch | Automatic switch |
