About Us:
Shengzhen Mountain A-Li Group Electronic Technology Co., LED. is a professional company manufacturing LED display system products for more than 10 years, established in 2000, covering a workshop area for 2000m2, with about 300 employees.
Products list:
| Item No.: | Description | Dimension | Brightness |
| | INDOOR | | |
| 1 | SMD indoor p3mm | 192mm*96mm | 2000cd/m2 |
| 2 | SMD indoor p4mm | 256mm*128mm | 2000cd/m2 |
| 3 | SMD indoor p5mm | 320mm*160mm | 2500cd/m2 |
| 4 | SMD indoor p6mm | 192mm*192mm | 3000cd/m2 |
| 5 | SMD indoor p7.62mm | 244mm*244mm | 2000cd/m2 |
| 6 | SMD indoor p10mm | 320mm*160mm | 3000cd/m2 |
| | OUTDOOR | | |
| 7 | DIP 3in1 outdoor P6 | 192*96mm | 7500cd/m2 |
| 8 | DIP 3in1 outdoor P7 | 224*112mm | 7500cd/m2 |
| 9 | DIP 3in1 outdoor P8 | 256*128mm | 8000cd/m2 |
| 10 | SMD 3in1 outdoor P6 | 192mm*192mm | 6000cd/m2 |
| 11 | SMD 3in1 outdoor P8 | 256mm*128mm | 6500cd/m2 |
| 12 | DIP 3in1 outdoor P10 round screen | 320*40mm | 8500cd/md |
| 13 | outdoor p10mm | 160mm*160mm | 8500cd/m2 |
| 14 | outdoor p12mm | 192mm*192mm | 7500cd/m2 |
| 15 | outdoor p13.33mm | 320mm*160mm | 5500cd/m2 |
| 16 | outdoor p16mm | 256mm*256mm | 7500cd/m2 |
| 17 | outdoor p20mm | 320mm*320mm | 7000cd/m2 |
Certificate:
![]()
Cases:
![]()
![]()
![]()
Advantage:
1. Low energy consumption,high brightness (brightness can be customized)
2. Low fault rate,long lifespan (2 more years lifespan than SMD board)
3. No color difference,large viewing angle (Horizontal 160°, Vertical 120°)
4. Optimal design,high-precision seamless,accurate to 0.1mm gap
5. Ultra-high refresh rate,can support video shooting,clear picture quality assurance
6. Quick and easy assembly,removing system,short loading time
7. Wide range of application
parameters:
| Item | Parameter |
| Product model | P8 SMD full color module |
| Module size | 320mm*160mm |
| Pixel pitch | 8mm |
| Pixel density | 15625dots/m2 |
| Pixel configuration | 3 in 1 |
| Module resolution | 32dots(W)*16dots(H) |
| Maximum power consumption | 25W |
| Module thickness | 2.8mm |
| Module weight | 0.55kg |
| Driving method | Constant current driving |
| Scan mode | 1/4 scan |
| Interface type | HUB75 |
| Brightness | ≥6200cd/m2 |
| The specifications of cabinet |
| Cabinet size | 640mm*640mm |
| Module quantity | 8pcs |
| Power supply | 5V/40A 5V/60A |
| Cabinet resolution | 96*96dots |
| Optimal viewing distance | 8m~50m |
| Optimal viewing angle | 160°(W) 120°(H) |
| Temperature | Storage:-35ºC~+85ºC
Working:-20ºC~+50ºC |
| System operating humility | 10%-95% |
| The specifications of power supply |
| Operating voltage | AC220V±10% |
| Average power consumption | 350W/H |
| Maximum power consumption | ≤800W/ |
| Current | ≤20mA(single LED) |
| The specifications of control system |
| Computer | Pentium4 or above |
| Operating system | WIN98/2000/NT/XP |
| Control model | Synchronization control |
| The specifications of the main technical parameters |
| Driving device | Constant current driving |
| Refresh rate | ≥600Hz |
| Grey scale | RGB each 256 grade, can display 16.7M colors) |
| MTBF | ≥9000hours |
| Power switch | Automatic switch |
| Display mode | 800*600/1024*768/1280*900 |
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
