Product Features : 1.Energy saving design, good cooling system, high definition, high cost, outstanding reliability and
complete function by the majority of new and old customers favorite
2.Ultra-high refresh rate, support the camera recorder, to ensure a clear picture quality
3.Quick editing of assembly, disassembly system, saving unloading time
Using Range: Widely used in a variety of needs large hall, sports arena, banking, telecommunications, government
agencies, terminal,pier, railway stations, the stock market and other trading market, medical systems,
:eletric power, galleries and other publicity, advertising, information diseemination, the guide places.
| Unit Module | Item | parameter |
| Model | P7.62 full color led module |
| Module size | 224mm*224mm |
| Pixel Pitch | 7mm |
| Pixel Density | 20408dots/m2 |
| Pixel Configuration | 1R1G1B 3in 1 |
| Package mode | SMD3528 |
| Module Resolution | 32dots(W)*32dots(H) |
| Max power consumption | 23W |
| Module Thickness | 2.7CM |
| Module Weight | 0.5KG |
| Driving Method | Constant Current Driving |
| Scan Method | 1/8scan |
| Interface Way | HUB75B |
| Brightness | ≥7000cd/m2 |
| Unit Module | dimension | 796mm X 796mm |
| Quantity of Module | 32PCS |
| Thermal discharge | fan 2pcs |
| Power supply Mode | 5V/40A 5V/60A |
| Pixel per cabinet | 96mm*96mm |
| Thickness | 85mm |
| Optimal Viewing Distance | 6M-40M |
| Optimal Viewing angle | 160°(W)120°(H) |
| Enviroment Temperature | Storage :-35ºC-+85ºC
work :-20ºC-+50ºC |
| Power | Relative Humidity | 10%-95% |
| Operating Voltage | AC220V±10% |
| Average power consumption | ≤350W/H |
| Max power Consumption | ≤600W/m2 |
| Current | ≤20mA (Single LED ) |
| Control system | CPU | Pentium4 or above P4 or above |
| Operate system | WIN98/2000/NT/XP |
| Control Mode | Synchronization with PC |
| Main technical parameter | Driving Device | IC Constant current driving |
| Refresh Rate | ≥600HZ |
| Gray/Color | RGB each 256 grade, can display 16.7M clolor |
| MTBF | ≥9000hours |
| Power Switch | Automatic Switch |
| Display Mode | 800*600/1024*768/1280*900 |
Why choosed us:
1.Price Advantage: No.1 cost effective
2.Quality advantage: serious QC control system , best material
3.Service advantage: after service dept& Tech Dept. Perfect after sales system
4.ISO9001,CE , CCC,ROHS Certificates
Trade Terms:
1.Packing: Anti-shaking wooden cabinet /Air flight case/carton
2.Shipping port: Shenzhen. China
3.Shipping freights are quoted according to your requests
4.Delivery time:10-15 working days
5.2 years warranty ,lifelong maintaining. In the Maintenance period, free of all maintenance charges.
After Maintenance period, only charge the material costs fees.
After-sales service:1. Service principles:Reponse in time, solve problems as soon as possible and ensure the use.Top
quality+reasonable price+responsible after service=successful & win .
2. Service period:In the Maintenance period of the LED screen body, free of all maintenance charges;
After Maintenance period, only charge the material costs fees free of manual work fees.
3. Service scope:If the users find any problem that cannot be solved, please contact with our company, we can
response in 24 hours.In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
4. Under normal use and storage, Our Company will be responsible for the equipments .Special service for big
project, such as stadium, exhibitions, squares and so on .
Pre-sales service:
1.Our company can arrange professionals to conduct site installation and debugging in strict accordance with the
requirements of the schemes and the original manual.If there is any special requirement, it is necessary to make
changes of part installation scheme, we will coordinate with users.Our company can ensure the consistence of
completion time and contracted time.Any problems caused by natural factors or man-made, we will discuss with
client to find solutions.
2. Our company can train the users based on the manual.The training include system use, system maintenance
and equipment protection
3. Support prints your logo on products and let your logo shine anywhere.OEM/ODM orders are warmly welcome.![]()
![]()
![]()
![]()
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
