About Us:
Shengzhen Mountain A-Li Group Electronic Technology Co., LED.
is a professional company manufacturing LED display system products for more than 10 years, established in 2000, covering a workshop area for 2000m2, with about 300 employees.
Products list:
Item No.: | Description | Dimension | Brightness |
| INDOOR |
|
|
1 | SMD indoor p3mm | 192mm*96mm | 2000cd/m2 |
2 | SMD indoor p4mm | 256mm*128mm | 2000cd/m2 |
3 | SMD indoor p5mm | 320mm*160mm | 2500cd/m2 |
4 | SMD indoor p6mm | 192mm*192mm | 3000cd/m2 |
5 | SMD indoor p7.62mm | 244mm*244mm | 2000cd/m2 |
6 | SMD indoor p10mm | 320mm*160mm | 3000cd/m2 |
| OUTDOOR |
|
|
7 | DIP 3in1 outdoor P6 | 192*96mm | 7500cd/m2 |
8 | DIP 3in1 outdoor P7 | 224*112mm | 7500cd/m2 |
9 | DIP 3in1 outdoor P8 | 256*128mm | 8000cd/m2 |
10 | SMD 3in1 outdoor P6 | 192mm*192mm | 6000cd/m2 |
11 | SMD 3in1 outdoor P8 | 256mm*128mm | 6500cd/m2 |
12 | DIP 3in1 outdoor P10 round screen | 320*40mm | 8500cd/md |
13 | outdoor p10mm | 160mm*160mm | 8500cd/m2 |
14 | outdoor p12mm | 192mm*192mm | 7500cd/m2 |
15 | outdoor p13.33mm | 320mm*160mm | 5500cd/m2 |
16 | outdoor p16mm | 256mm*256mm | 7500cd/m2 |
17 | outdoor p20mm | 320mm*320mm | 7000cd/m2 |
Our Advantages:
1.High quality:
Use high quality LED with high luminous efficiency and low brightness decay to make the display stable.
2.Good effect:
To show vivid and clear pictures with high resolution, but low cost; Has good display effect in both pictures and letters because of using real pixel technology.The products support multiple display modes.
3.Easy maintenance:
Can fix the single point to save the maintenance cost.
4.Good uniformity:
Brightness difference within 10% between any two LEDs, to ensure the brightness and color uniformity of the display; Good uniformity in color solve the problem of mosaic well
5.Price
No. 1 cost effective. The price is very good, please contact us for an offer. You can compare and know!
6.Application
It's wide Application, such as stage rental events, exhibition, wedding, advertising, meeting room and so on.
Features Introduction:
1)High intensity and can be adjusted, so can meet the request of the customers according the application environment.
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light
3) To pictures and character, have clear, exquisite and real display effect
4) Can repair each led lamps, so the cost of maintain is lower, and easy to repair.
Parameter
The specifications of modules |
|
Items | Parameter |
Product Model | P6 Indoor Full Color Led Module |
Module size | 244mm*244mm |
Pixel pitch | 4mm |
Pixel density | 17222dots/m2 |
Pixel configuration | 1R1G1B |
Module resolution | 32dots(W)*16(H)dots |
Module maximum power consumption | 15W |
Module Thickness | 15MM |
Module Weight | 0.45kg |
Driving method | Constant Current Driving |
Scanning method | 1/48 scan |
Interface | HUB75-A |
Brightness | ≥ 1700cd/m2 |
The specifications of cabinets |
|
Cabinet size | 976mm*976mm |
Module quantity | 16pcs |
Power supply | 5V/40A 5V/60A |
Cabinet resolution | 128*128dots |
Optimal viewing distance | 8M~100M |
Optimal viewing angle | 160°(W) 120°(H) |
RHWorking temperature | (Work :-20°C~+60°C) |
System operating humility | 10%-95% |
The specifications of power supplier |
|
Operating Voltage | AC220V±10% |
Average power consumption | 350W/H |
Maximum power consumption | ≤400W/M2 |
Electric current | ≤20mA(single LED) |
The specifications of control card |
Control Panels | Pentium4 or above |
Operating system | WIN98/2000/NT/XP |
Control model | Synchronization with PC |
The specifications of the main technical parameters |
|
Driving device | Constant Current Driving |
Refresh rate | ≥600HZ |
Grey scale | RGB Each 256, can display 16.7M colors) |
MTBF | ≥9000hours |
Power switch | Automatic Switch |
Display Mode | 800*600/1024*768/1280*900 |
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
