Home LED Light Products P5 Indoor Full Color LED Display with Low Consumption

P5 Indoor Full Color LED Display with Low Consumption

P5 Indoor Full Color LED Display with Low Consumption
Price: US $ 720-850/Square Meter
Trade Terms: FOB,CFR,CIF
Min Order: 1/Square Meter
Pay Type: T/T,Western Union






Unit module
ItemParameter
Module NumberALS-P5-16S
Module size320m*160mm
Pixel pitch5m
Pixel density40000dots/m²
Pixel configuration1R1G1B
Package modeSMD 3528
Pixel resolution64dots(W)*32dots(H)
Max power consumption25W
Module thickness14.27(without magnet)
26.6(with magnet)
Weight0.21kg
Drive typeConstant Drive
Scan mode1/16scan/1/8scan
Interface wayHUB75-A
Brightness of white balance>=1600cd/m²/ >=2800cd/m²

Unit cabinet
Cabinet size640mm*640mm
Quantity of Module16
Thermal dischargefan 2pcs
Power supply mode5V/40A*2pcs
Pixel per cabinet128mm*128mm
Optimal viewing distance5M~30M
Optimal viewing angel160°(W)120°(H)
Working TemperatureStorage:-35 ºC ~+85 ºC
Work:-20ºC~+50ºC
Relative humidity10%-95%
Thickness85mm

Power
Operating voltageAC20V±10%
Average power consumption<=180m²/ <=270m²
Max power consumption≤500W/m²/ ≤800W/m²
Current≤20Ma(sign LED)
Control systemCPUPentium4 or above
Operation systemWIN98/2000/NT/XP
Control methodSynchronization with PC
Main technical parameterDriving deviceIC Constant Current Driving
Refresh frequency≥400HZ
Grey scale/colors256rade level/16.7M color
MTBF≥9000hours
Power switchAutomatic switch
Display mode800*600/1024*768

Products Features

1) With good lightening accordance and no mosaic

2) LED advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment

3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced

4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment

5) Uses real pixels rather than virtual pixels, better viewing effect

Applications:

LED advertising board wide applied in stadiums, advertising, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc


What can we provide with you ?

   We are Shenzhen Mountain A-Li Group Electronic Technology Co.,LED. We have opened many sub-office in different provinces and cities in China. And we also have already have office in Kazakhstan, Russia, Thailand , Turkey, India, South Africa, Belgium, Singapore, Malaysia, Indonesia, Colombia, Brazil. Now our products are widely used in dozens of countries worldwide, continue to emerge in the international renowned events and occasions, capture and focus the imagination of millions of viewers.

1. Formal company, 8 years of experience ,courteous service

2.Manufacturers delivery, higher quality at low price than trade company

3.Products can be customized, professional design, your satisfaction is guaranteed

4 Satisfied with the consulting services and after-sales service.

Installation

    We offer you the engineer to install the LED display, you have to offer him the two-way air tickets and accommodation as well as visa. The engineer's salary is $80/day;or we offer you the training on the LED display installation and repairing for free after you live in our company, or we can guide you to install the screen by remote control.

How about your quality warranty?

    It is 2 years quality warranty and lifetime technology support and maintenance from the second year. If you improperly operate or something wrong with our products, we are responsible for the maintaining and repairs instruction or guide free of charge.

Trade Terms

1. Trade terms: EXW, FOB, CIF, etc.

2. Payment terms: 30% deposit, balance before shipping

3. Payment methods: T/T, West Union, MoneyGram,

4. MOQ:1(1 square meter)

5. Delivery:7-15days after deposit.

6. FedEx/DHL/UPS/TNT for samples, Door-to-Door;

Prod Model: P5 Indoor Full Color LED Display
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Module Size: 320mm*160mm
Cabinet Size: 640mm*640mm
Cabinet Resolution: 128*128dots
Brightness Of White Balance: ≥1600CD/M²
Interface Way: Hub75-a
Drive Method: Constant Drive
Optimal Viewing Distance: 5m~30m
Optimal Viewing Angel: 160°(W)120°(H)
Grey Scale/Colors: RGB Each 256 Grade
Display Mode: Can Display 16.7m Color
Tube Chip Color: Full Color
Display Function: Video Display
Pixel Pitch: 5mm
Pixel Configuration: 1R,1G,1B
Pixel Density: 40,000 dots / m²
Scanning Mode: 1/16 Scan
Display Type: LED Video Display
Application: Hall/Advertising/Information Dissemnation
Certification: FCC, EMC, ISO: 2008
System Operating Platform: Win98/2000/Nt/XP
IP Rating: IP31
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
