Superior Color Performance
20bit processing depth and high precision calibration help create vivid and brilliant colors, sharp and smooth images can attract passing by to boost ad revenue.
High precision calibration supports calibrate in pixel level, module-level, whole screen and onsite calibration, keep the outstanding performance of the display in long term.
Extremely wide viewing angle attracts more audience.
Extreme Low Power Consumption
Saves electricity costs, reduces operation costs, and ensures LED display's long term working stability, extends lifespan.
Front & Rear Access Available
Unique mechanical design enables modules to be installed or removed in seconds from both front and rear side.
EMC Class-B
NO electromagnetic interference in living environment.
Remote Monitor& Diagnostic System
Automatically monitor the display working status in 24/7, support feedback and alarm on abnormal situation.
| Item | P4 |
| LED type | SMD 3 in 1 |
| Pixel Configuration | 1R1G1B |
| Pitch | 4mm |
| Pixel Density(/m2) | 62500pixels |
| Brightness(cd/m2) | 1200 |
| Scaning | 1/16 |
| Viewing Angle | H≥140° V:≥120° |
| Driving Mode | Constant current |
| Grey scale | 4096 |
| Repetition Frequency | ≥60HZ |
| Refresh rate | ≥1200HZ |
| Max power consumption(W/m2) | ≤800 |
| Average Consumption(W/m2) | ≤200 |
| Life time(H) | ≥100000 |
| Continuous work time(H) | ≥72 |
| Operating environment | -10ºC~40ºC , 10%~90%RH |
| Protection classification | IP30 |
AOTO Electronics (Stock: 002587), which founded in 1993, is specialized in designing and manufacturing high quality LED applications and financial electronic products.
In the field of LED display system, AOTO foucus on the high profile market, and its products has been widely used in advertisement, sports, events and TV studios. AOTO provides LED display solutions including demand analysis, system design, product R&D, manufacturing, engineering and other services. AOTO is in the leading position of information display systme and customer classification service and its products are popular in financial and telecommunication industries.
