Lightweight Modular Design and Thin
Modular design and thin - 480mmx480mmx77mm, One cabinet is less than 10kg.
Superior Color Performance
24bit processing depth and high precision calibration help create vivid and brilliant colors, sharp and smooth images can attract passing by to boost ad revenue.
High precision calibration supports calibrate in pixel level, module-level, whole screen and onsite calibration, keep the outstanding performance of the display in long term.
Extremely wide viewing angle.
Seamless Splicing
Accurate and solid mechanical design are suitable for fixed installation for long-term use, ensure seamless splicing between cabinets.
Extreme Low Power Consumption
Saves electricity costs, reduces operation costs, and ensures LED display's long term working stability, extends lifespan.
Zero Noise
Fanless design makes sure whisper-quiet operation.
World Leading Outdoor SMD Application
SMD 3 in 1high quality with brilliant performance and visual impact attract audience's attention and enhance the effect.
IP Rating for Harsh Environment
IP66 can be used for indoor and outdoor all-weather installation environment.
EMC Class-B
No electromagnetic interference in living environment.
Remote Monitoring & Diagnostic System
Automatically monitor the display working status in 24/7, support feedback and alarm on abnormal situation.
| Item | P3.0 | P2.5 | P2.0 | P1.7 | P1.5 |
| LED Type | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 |
| Pixel Configuration | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| Pitch | 3.0mm | 2.5mm | 2.0mm | 1.78mm | 1.58mm |
| Pixel Density(/m2) | 111111pixels | 160000pixels | 250000pixels | 316406pixels | 401111pixels |
| Brightness(cd/m2) | 1500 | 1200 | 1000 | 1200 | 1000 |
| Module Pixel | 160*160 | 192*192 | 240*240 | 270*270 | 304*304 |
| Viewing Angle | H≥160° V:≥160° | H≥160° V:≥160° | H≥160° V:≥160° | H≥160° V:≥160° | H≥160° V:≥160° |
| Grey scale | 20Bit | 20Bit | 20Bit | 20Bit | 20Bit |
| Colour | 1,153 quadrillions | 1,153 quadrillions | 1,153 quadrillions | 1,153 quadrillions | 1,153 quadrillions |
| Max power consumption(W/m2) | ≤715 | ≤715 | ≤715 | ≤715 | ≤715 |
| Average Consumption(W/m2) | ≤300 | ≤300 | ≤300 | ≤300 | ≤300 |
| Life time(H) | ≥100000 | ≥100000 | ≥100000 | ≥100000 | ≥100000 |
| Input Voltage | AC100-240V,50/60Hz | AC100-240V,50/60Hz | AC100-240V,50/60Hz | AC100-240V,50/60Hz | AC100-240V,50/60Hz |
| Operating environment | -30ºC~40ºC , 10%~90%RH | -30ºC~40ºC , 10%~90%RH | -30ºC~40ºC , 10%~90%RH | -30ºC~40ºC , 10%~90%RH | -30ºC~40ºC , 10%~90%RH |
| Protection classification | IP30 | IP30 | IP30 | IP30 | IP30 |
