Smart Series HD P3 Indoor LED screen display full color
-Main features.
1.Fast assembly:
It could be installed without complicated tools in hanging and fixed installation.
2.Light weight:
With the min-depth 9.7mm, each cabinet weigh only 4.2kg.
3.Energy saving:
The power consumption for each cabinet is only 80W.
4.Colorful performances:
Smart Series P3 is equipped with black LED 2020.The high-density, vivid color processing guarantees you high-end broadcasting show.
Visual Parameter
Pixel Pitch:
3mm
Pixel Density:
111,111 pixels / Square meters
Pixel Configuration:
SMD2020
Module Dimension:
192*96 mm
Module Resolution:
64*32 pixels
Cabinets Dimension:
384*384*64.7 mm
Cabinets Resolution:
128*128 pixels
Cabinets weight:
4.2kg/cabinet
Cabinet Material:
Aluminum alloy
Performance Parameter
Brightness:
1,400cd/Square meters
Best Viewing Distance:
> 3m
Max Consumption:
80W/cabinet
Scan Mode:
1/16 scan
Viewing Angle:
Horizontal angle: 140 degree Vertical angle: 140 degree
Gray Scale Level:
16 bit
Refresh Rate:
1,200Hz
LED Lifetime:
50,000 hours
Environment Parameter
Input Voltage:
90~260VAC, 50/60Hz
Operation Humidity:
10%~99%
Ingress Protection:
IP20
Control Parameter
Control System:
NOVASTAR
Signal:
DVI up to UXGA,SDI, HD-SDI,S-video,compositem,YUV
Our company supplies different kinds of products. High quality and favorable price. We' Re pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
