Smart Series HD P4 Indoor LED screen display full color
-Main features.
1.Fast assembly:
It could be installed without complicated tools in hanging and fixed installation.
2.Light weight:
With the min-depth 9.7mm, each cabinet weigh only 4.2kg.
3.Energy saving:
The power consumption for each cabinet is only 80W.
4.Colorful performances:
Smart Series P3 is equipped with black LED 2020.The high-density, vivid color processing guarantees you high-end broadcasting show.
echnical Data\Model
PH4
Pixel Pitch
4mm
Physical Density(pixels/m²)
62500
LED Shape & Size
SMD 3 in 1
LED Arrangement
1R1G1B
Module Size(mm)
128×128
Module Resolution
32*32
Drive Mode
Dynamic 1/8 Duty Constant Current
Brightness
≥1500cd/m²
Contrast(cd/m²)
≥2000:1
View Angle, 50% Brightness
140°/140°
Minimum View Distance
4m
Grey Scale
10bits/1024levels
Color Capacity
1.07billion
Maximum Power Consumption
860W/m²
Ave.Power Consumption
280W/m²
Operation Power Source
AC90-260V 50-60HZ
Frame Frequency
60-85HZ
Refresh Rate
240-1000HZ
Brightness Adjustment
0-100% 8 levels automatic
Gamma Correction
-5.0-5.0
Correction Scale Level
16bits
Color Temperature
5000-9300K
Brightness Correction
Pixels, Module, Cabinet Correction
Input Source Support
Composite, S-Video,Component,VGA,DVI,HDMI,SDI, HD_SDI
Control Distance
UTP CAT5E:100m;Multi-mode Fiber:50m;Single-mode Fiber:10km
Operating Temperature
-40°C - 65°C
Operating Humidity
10-90%RH
Operating Life Span
100,000Hours
MTBF
5000 Hours
Protection Ratings
IP31
Out of Control Rate
0.01%
