1.We use SMD3528,the white lamp,but the LED lamp is specially customer made,
there is gluing inside,its can UV-proof,and the brightness is higher than normal 3528.
2.The transparency more than 75 percent.
3. Most competitive price, the cabinet weight is 15kg/sqm,ultra light and super thin.
4. Easy installation and maintenance, can show lighting, graphics, text, animations or video content.
5.If the glass wall has color ,will influence the color temperature of our led lamp.
So we need to make adjustment to make the showing effect is the best .
6. Top quality, we control all steps from design to production which guarantee the quality and reliability.
7. Long life span and good after sales service.
8.Its use Dianshanyuan power supply,the desigh without fan, no noise,natural heat dissipation
9.The screen use indoor,install behind the glass,not waterproof
Project | P10 |
Pixel Pitch | 10mm |
Pixel density(dots/sqm) | 10,000 |
LED | 3528 |
Module size(mm) | 320*320 |
Module pixel | 32X32 |
Brightness (CD/ sqm ) | 5000~6500 |
Transparent | ≥80% |
Max power consumption | 1000 w/sq.m |
Ave power consumption | 390 w/sq.m |
Viewing angle | Vertical:140°(+70°/-70°); Horizontal:140°(+70°/-70°) |
Refresh Frequency | more than 1920 Hz/s |
Frame Frequency | 60fps |
Screen thickness | 10mm |
Protective grade | IP45 |
Control system | Dbstar,Linsn,Novastar |
Operating temperature | -10°C~+45°C |
Operating humidity | 10%-95%RH |
Display weight(not including power) | 13--15kg/sqm |
Installation method | Varieties installation method,specific scheme with the direction book |
