Indoor fullcolor advertising LED display screen features:
Quiet fan design, excellent heat dissipation, noiseless, the preference for indoor use.
Concealed quick lock between the cabinets horizontally, just one switch, then all set.
Crane padlock vertically connected, convenient for installation.
High polymer flexible mask, no dazzle, better contrast ratio.
High-performance metal plate cabinet, concise cable.
The sealed type back cover, effectively prevent the wrong operation of the amateur.
|
P10 |
Classification of items |
|
Indoor Full Color LED SMD Display P10 |
|
Module |
Pixel Pitch |
10mm 3-1 SMD |
|
Module size |
160*320 MM |
|
Density of pixel |
10,000dots/sqmt |
|
Pixel constitation |
1R 1G 1B |
|
LED encapsulation |
546 |
|
Brightness adjustment |
256 grade automatic, 8 grade manual |
|
Specifictaion |
Singal Input |
VGA,AV,S-video,DYI,HDMI,SDI |
|
IP RATING ( Front / Rear ) |
IP43/IP21 |
|
Display brightness |
1,600cd/ sqmt |
|
Driving Mode |
1/4 |
|
Frames changing rate |
More than 60hz/s |
|
Refresh rate |
More than 1200hz/s |
|
Optimum viewing distance |
5m-100m |
|
Optimum viewing angle |
H :140° V:140° |
|
Power consumption |
Max:450w/sqmt,Average: 180w/sqmt |
|
Control Mode |
To be synchronized with computer monitor |
|
Data Transmission |
Parallel RS422 mode |
|
Screen body weight |
Less than 60KG/PCS |
|
Working environment temperaure |
-40C~60C |
|
Opearation voltage |
AC240V±15% / AC 110V±15%, 50~60HZ |
|
Grey scale/color |
256 scale / 16M |
|
Brightness adjustment |
Manual Y color 256 Grade /automatic 8 grade |
|
Average no failure time |
More than 50000 hours |
|
Life span |
More than100,000hours |
|
Malfunction dot rate |
Less than 0.0003 |
|
Computer system |
WIN98,WIN2000,WINXP |
Shenzhen Eastar Electronic Co., Ltd., is an integrated service supplier of LED display screens headquartered in the city of Shenzhen, China.After six years professional experience in LED R&D significantly guarantees high quality of the products which have been exported to more than 80 countries and regions in the world, such as USA, UK, Italy, Belgium, etc.Our effective management and prompt and creative services have won a good reputation from our customers from all over the world.
Our manufacturing center is equipped with world class manufacturing equipment.Now, there are 3 YAMAHA SMT high speed mounters, 2 auto colorgraph and beam splitting machines, backflow welding machines, wave crest welding machines, and supersonic wave cleaning machines.We take advertage of the latest technology to meet the ever-demanding needs of the market.So All above these machines is operated automatically, promote our efficiency and ensure our products high quality.
EASTAR strictly implements the 5S production management system and ISO2001 Quality Control System.Up to now, we have the UL, CE, RoHS, etc certificatios.Meanwhile, we are on the way of applying new quality control certifications and keeping the principle 'customers and Quality come first' in our mind to make sure everystep operated normally and eliminate the mistake at the first time.
Come and talk to one of our representatives, whether you are interested in buying a LED display screen, or you are looking for a good supplier to work with in your market.We are willing to share our experience with you and we will also share with you the satisfcation brought by a good piece of product, or the success brought by our faithful cooperation!So welcome to join us!
