Outdoor Vehicle & Vessel LED Display (PH10)
Price: |
Negotiable/Piece |
Trade Terms: |
FOB,others |
Min Order: |
5/Piece |
Pay Type: |
T/T |
Outdoor Vehicle & Vessel LED Display pH10:
With the features of shock-proof, wind resistance, good movability, convenience&fast and so on, vehicle LED display is mainly welcomed by various large-scale activities, such as road show, opening celebration, building opening, business promotion, exhibition publicizing, field pick up, information releasing, civilization in community, military affairs drilling, motor exhibition, sport game. More eyes are concentrated, better advertising result is won.
Display and control feature |
Structure feature |
Specification |
Parameter |
Specification |
Parameter |
Pixel Pitch |
10 mm |
Module size |
160 mm*160 mm |
Pixel composing |
1R1G1B |
Display resolution/module |
16 dots*16 dots |
Wavelength (R) |
620-630nm |
Standard cabinet size |
960 mm*800 mm |
Wavelength (G) |
520-535nm |
Cabinet Weight |
≤ 65 Kg/sqm |
Wavelength (B) |
465-475nm |
Protection classification |
IP65 |
Wave Angle (H) |
110° (H)/ 50° |
Install mode |
Wallmount, hung and stand structure |
LED package |
DIP 346 |
Cabinet Material |
Iron/Aluminum |
Density per sqm |
10, 000 pixel |
Working power |
Grey scale |
12-16bit |
Specification |
Parameter |
Whiteness brightness |
≥ 5500 |
Working voltage |
AC 220v/50Hz± 10% or AC110v/50Hz± 10% |
Frame frequency |
60 Hz |
Average/Max power |
650W/1600W per sqm |
Refreshing frequency |
900-10, 000Hz |
Short circuit protection |
Yes |
Driving method |
1/4 Constant Driving |
Led Lamp type |
Nichia/Cree/Silan/OPTO |
Control mode |
synchronous |
Working environment |
Display port |
DVI |
Environment |
Outdoor |
Malfunction dot |
3/100, 000 |
Working temperature |
--20~50 |
MTBF |
10, 000 hours |
Working Humidity |
10~90% |
Prod Model: |
PH10 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Pixel Configuration: |
1R, 1G, 1B |
Pixel Pitch: |
10mm |
Pixel Density: |
10000 dot / m² |
IP Rating: |
IP65 |
Tube Chip Color: |
Full Color |
Display Function: |
Video Display |
Scanning Mode: |
1/4 Scan |
Certification: |
CE |
Average Power Consumption: |
650W/Sqm |
Shenzhen Leder Electronics Co., Ltd. Locates in E Building, the new world of Science and Technology Industrial Park, XiaShiJia, Gongming Street Guangming New Area, ShenZhen, Guangdong, China. LEDER is the high & new technology enterprise specializing in the Research & Development of LED displaying products, production, sales, engineering service, etc.
Based on more than 10 years of outstanding development, LEDER becomes one of the most advanced LED display manufacturers in China and also one of the biggest professional LED display manufacturers in Southern China.
With modern workshop for electronic processing, assembling, adjusting and aging, LEDER ensures the production capability of 20000 m2 LED display for all types yearly, and is able to provide one package service for our clients from consultant, production, installation, adjustment & test, training to after service.
LEDER positively practices the environmental protection and energy saving. In 2008, LEDER firstly launched OUTDOOR SMD (5050, 5060) 3IN1 FULL COLOR LED DISPLAY. Solved 3 difficult problems on outdoor SMD LED Displays successfully - brightness, heat extraction and water proofing, and made-up deficiencies of the traditional LED Display of small viewing angle, module's nonuniform color, large power consumption, overweight, and so on. In 2009, LEDER brought out LED lighting products: Flexible LED video strip, LED flexible strip, LED video pels light, LED module^^, which attracts batches eyes and gains very good comment from experts and audients.
Since the foundation, LEDER has been insisting the tenet of "Build first-class brand, win with superior quality and service", and has actively conducted the ISO 9001 system, its products have been awarded certificates such as CE, RoHS. Besides owning a few of independent core technology and patents, LEDER firstly built up the enterprise standard, which effectively promotes the healthy development of Chinese LED display industry. Successively, LEDER undertakes batches of high quality projects in domestic and oversea. Now LEDER has jumped to be the biggest professional LED display manufacturer in ShenZhen, and has set up its leading position in optoelectronic industry, and to be as sponsors at the 16th Asian Games.
LEDER's General Manager has been directly working on the management of R&D, production, engineering, and after-service for more than 15 years. He has experienced the stage of starting, developing and maturing of China's LED Display industry. He would like to cooperate with all customers, leading all of LEDER staffs, to witness the prosperity of LEDER and LED Display industry together.
"Share our successful happiness with our clients" is the business concept we always keep. With your continuing care and support, we, together enter to LED products' energy saving, colorful, and bright future.
