P10 outdoor Rental Die cast Alumium LED Display 640 mm x 640mm
Outdoor Rental LED Display detail specication | Parameters | Outdoor Die-casting LED Display Series ( 640 MM X 640MM ) |
| Pixel Pitch (mm) | 6.67mm | 8mm | 10mm | 10mm |
| Pixel density(pix/m2) | 22545 | 15625 | 10000 | 10000 |
| LED Type | 3535 | 3535 | 3535 | Dip346 |
| Viewing Angle | X,Y140° | X,Y140° | X,Y140° |
| Brightness(nits) | ≥5000 | ≥5000 | ≥5000 |
| Drive Method | 1/6 | 1/5 | 1/4 |
| Color Depth | 65536 |
| Refresh Rate(Hz) | 1920 | 1920 | 1920 |
| Module Size (mm) | 320×160×16 |
| Cabinet Size(mm) | 640×640×80 |
| Cabinet Material | aluminum |
| Cabinet weight(kg) | 12 | 17 | 17 |
| Voltage | 200-240V |
| Average.power(W/m2) | 230 | 230 | 230 |
| Max.power (W/m2) | 700 | 700 | 700 |
| IP Grade | IP65/IP54 |
| Operating temperature/humidity | temperature:-20ºC~ 50ºC humidity:10~90%RH |
| Storage temperature/ humidity | temperature:-40ºC~ 60ºC humidity:10~90%RH |
| Lifetime(h) | ≥50000 |
| Compliant Standard | CCC(CE)Rosh |
Die cast Alumium outdoor Rental LED Display feature :1 . Super Slim LED display is designed for indoor and outdoor LED display R & D leases. Synchronous control system processing, accept DVI, VGA, HDMI, S-video, composite, YUV input signals, etc., free video, graphics, images, and Mao's program in real time, synchronization, clear information dissemination play each kind of information, and can display 2D and 3D animation, video, TV, VCD programs, and live and so on.
2 As a new type of advertising display design makes stable, durable, easy to use, suitable for indoor stage, television and other application areas. Achieved without tools to quickly install and maintain, greatly expanding the use of the product areas. High production efficiency and lower operating costs.
3 . Super thin and light weight (thickness :75mm weight :7kg), easy to install and transport.
Aluminum die-casting cabinet, automatic heat dissipation, and low power consumption.
Seamless connection with high flatness and soft image .
4 .Support point correction function, ensure the color and brightness consistency.
High RGB gray scan processing, colorful, vivid and clear viewing effect.
High stability and reliability with integrated circuit .
Accurate and fast installation with buckled cabinet design, which can be used in different application.
One case with multi-purpose, product upgrading only need to change the module , low upgrade cost.
5 Buckle cabinet design makes it fast installation and dismantle, both for fixed installation and rental using. Professional and standard air plug with high quality guarantee.
