Prod Model: |
Outdoor P10 Full Color |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
LED Module Size: |
160mm*160mm |
LED Module Resolution: |
16 Dots*16 Dots |
LED Module Weight: |
0.55kg |
Brightniess: |
7500-8500mcd/Square Meter |
Cabinets Size: |
960mm*960mm |
Best View Distance: |
10-100m |
LED Modules Max Power: |
25W |
Modules Thickness: |
25cm |
Warranty: |
2 Years |
Export Markets: |
Global |
IP Rating: |
IP67 |
Pixel Pitch: |
10mm |
Pixel Configuration: |
1R, 1G, 1B |
Display Function: |
Video Display |
Average Power Consumption: |
600W / m² |
Pixel Density: |
10000 dot / m² |
Scanning Mode: |
1/4 Scan |
Display Type: |
LED Video Display |
Application: |
Advertising |
Certification: |
FCC |
Product Description
Product Description:
Advantage:
1.Price Advantage: No.1 cost effective
2.Quality advantage: serious QC control system , best material
3.Service advantage: after service dept& Tech Dept. Perfect after sales system
P10 led display screen led sign full color outdoor display 2years warranty , delivery time :10-15 days
P10 Full Color Outdoor LED Display technical parameter : |
Unit Module | Item | parameter |
Model | P10 FULL Color Led Module |
Module size | 160mm*160mm |
Pixel Pitch | 10mm |
Pixel Density | 10000dots/m2 |
Pixel Configuration | 1R1G1B |
Module Resolution | 16dots(W)*16dots(H) |
Max power | 20w |
Module Thickness | 25cm |
Module Weight | 0.5kg |
Driving Method | Constant Current Driving |
Scan Method | 1/4 scan |
Interface Way | HUB75 |
Brightness | ≥7500cd/m2 |
Unit Module | Cabinet Size | 960mmx960mm |
Cabinet Composing | 36pcs |
Power supply Mode | 5V/40A 5V/60A |
Cabinet Resolution | 96*96dots |
Optimal Viewing Distance | 10M-50M |
Optimal Viewing angle | 160°(W)120°(H) |
Enviroment Temperature | Storage :-35ºC-+85ºC work :-20ºC-+50ºC |
Power | Relative Humidity | 10%-95% |
Operating Voltage | AC220V±10% |
Average power | 350W/H |
Max power Consumption | ≤700W/m2 |
Current | ≤20mA (Single LED ) |
Control system | Computer | Pentium4 or above P4 or above |
Operate system | WIN98/2000/NT/XP |
Control Mode | Synchronization with PC |
Main technical parameter | Driving Device | IC Constant current driving |
Refresh Rate | ≥600HZ |
Gray/Color | RGB each 256 grade, can display 16.7M clolor |
MTBF | ≥9000hours |
Power Switch | Automatic Switch |
Display Mode | 800*600/1024*768/1024*900 |
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
