P25 outdoor LED Display
Noveled Group Co. Ltd is the leading OEM manufacture of LED Display Screens and LED light in China...We can supply LED Display, LED Screen, LED Sign, LED Video Display, Full color indoor LED display, Full color outdoor LED dislay. LED Panel, LED billboard, LED advertising display, LED display board, LED display module.
1) We make the whole produce process under the anti-static control, to prevent the harm of static and reduce the rate of burning out. Now the dead DOT rate of our outdoor LED display can be controlled within 1/10, 000.
Product Description:
Function and Technology Character
(1) Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
(2) Information source can be camera, video, VCD, DVD, LD, TV and so on.
(3) Clear picture without flicker and distortion.
(4) Brightness, contrast, saturation can be adjust by itself and manual.
(5) Show everything with your PC does synchronously.
(6) Super correcting technology for distortion.
(7) One interface for sound signal and two for video signal at least.
(8) Connected and controlled by PC via LAN and remote control.
(9) Multiform language editions, such as English, French, Germany, Greek, Russian and so on.
| Specification | Parameter |
| Pixel Pitch | 25 mm |
| Pixel composing | 2R1G1B |
| Density per sqm | 1600 pixel |
| LED package | DIP 546 |
| Wavelength(R) | 625~630nm |
| Wavelength(G) | 525~530nm |
| Wavelength(B) | 470~475nm |
| Led Lamp type | Nichia/Cotco-Cree/Silan |
| Module size | 200 mm*200mm |
| Display resolution/module | 8 dots*8 dots |
| Standard cabinet size | 1000*1000mm |
| Weight per sqm | 70Kg/sqm |
| Protection classification | IP65 |
| Wave Angle (H) | 140° (H)/ 60° |
| Display color | 256*256*256 |
| Whiteness brightness | ≥ 5000 |
| Changing frame frequency | 60 Hz |
| Refresh | 400 Hz |
| Driving method | Constant Static |
| Control way | Real or Virtual Pixel |
| Max power/sqm | 500W/sqm |
| Average power/sqm | 200W/sqm |
| Working voltage | AC 220± 10%50Hz or AC 110± 10%60Hz |
| Short circuit protection | Yes |
| Working temperature | -20~50 centigrade |
| Working Humidity | 10~90% |
| Out of control | 1/10, 000 ( scattered) |
| Lifetime | 100, 000 hours |
| Environment | Outdoor |
| Install mode | Wallmount, upright post |
| Control mode | Synchronous |
| Display port | DVI |
| Display mode | 1024*768 /1024*1024 |
