About Us:
Shengzhen Mountain A-Li Group Electronic Technology Co., LED.
is a professional company manufacturing LED display system products for more than 10 years, established in 2000, covering a workshop area for 2000m2, with about 300 employees.
Products list:
| Item No.: | Description | Dimension | Brightness |
| INDOOR |
|
|
| 1 | SMD indoor p3mm | 192mm*96mm | 2000cd/m2 |
| 2 | SMD indoor p4mm | 256mm*128mm | 2000cd/m2 |
| 3 | SMD indoor p5mm | 320mm*160mm | 2500cd/m2 |
| 4 | SMD indoor p6mm | 192mm*192mm | 3000cd/m2 |
| 5 | SMD indoor p7.62mm | 244mm*244mm | 2000cd/m2 |
| 6 | SMD indoor p10mm | 320mm*160mm | 3000cd/m2 |
| OUTDOOR |
|
|
| 7 | DIP 3in1 outdoor P6 | 192*96mm | 7500cd/m2 |
| 8 | DIP 3in1 outdoor P7 | 224*112mm | 7500cd/m2 |
| 9 | DIP 3in1 outdoor P8 | 256*128mm | 8000cd/m2 |
| 10 | SMD 3in1 outdoor P6 | 192mm*192mm | 6000cd/m2 |
| 11 | SMD 3in1 outdoor P8 | 256mm*128mm | 6500cd/m2 |
| 12 | DIP 3in1 outdoor P10 round screen | 320*40mm | 8500cd/md |
| 13 | outdoor p10mm | 160mm*160mm | 8500cd/m2 |
| 14 | outdoor p12mm | 192mm*192mm | 7500cd/m2 |
| 15 | outdoor p13.33mm | 320mm*160mm | 5500cd/m2 |
| 16 | outdoor p16mm | 256mm*256mm | 7500cd/m2 |
| 17 | outdoor p20mm | 320mm*320mm | 7000cd/m2 |
Our features and advantages:
1. Our special PCB design can save 30% power consumption compared with common product
2. High brightness(over 7500nits) and can be adjusted automatically accordingly to the environment;
3. IP65 waterproof front. With a special cover on the rear side of cabinet, it can avoid water very well
4. No gap between adjacent cabinets so surface is smooth. It has vivid color reproduction, no mosaic;
5. Aluminum cabinet, lighter and not easy to go rusted.
6. Any single dead lamp can be reaired respectively, which reduce the cost of maintenance.
7. Can reach wide viewing angle. You can get vivid effect within any position of the viewing range;
It can be FLAT or Curved as per your requirements.
Parameters
Technical Parameters |
| PROJECT | P6 full color outdoor LED display screen |
| Pixel pitch | 6mm |
| Pixel density | 27777dots/sqm |
| Module size(W*H) | 256 (mm)W*256 (mm)H
|
| Module pixels(W*H) | 32Pixels(W)*16 Pixels(H)
|
| Pixel configuration | 1Red 1Green 1Blue |
| Drive mode | constant current driving static scan |
| LED lamp type | Epistar DIP346 |
| Cabinet size(W*H*D) | 768 (mm)W*768 (mm)H |
| Cabinet resolution | 128 Pixels(W)*128 Pixels(H)
|
| Color scale | RGB each 256 grade, can display 16.7M colors) |
| View angle(H/V) | 160°(W) 120°(H) |
| Brightness (White balance) | ≥7500cd/sqm. |
| Power consumption(one cabinet) | Average:350W/sqm. |
| Operating Voltage | AC100V±10% or 220V ±10% |
| Operating temperature | -20°C----+50°C (Customized power supply:-45°C---+60°C) |
| Operating humidity | 10%_95%RH |
| Life time | ≥100,000hours |
| MTBF | 9000hours |
| Whole Display Flatness | ≤0.1mm Juncture |
| Refresh rate | ≥600Hz /s |
| Control distance | 100m (without repeater), single mode fiber:20km, multi mode fiber: 500m |
| Power | 110V/220V±15% 50--60Hz |
| LED control system | LINSN,Dbstar,Nova-star,ZDEC,Colorlight is selectable |
| Operating system | Windows 2000 / Windows Xp |
| Protections for outdoor display | IP65 |
| Maintenance way | Rear Access |
| Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI
|
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
