OEM&ODM High Power 60W LED Solar Street Light with Aluminum Body Meanwell Driver
IP65 Warranty 5 Years road lamp lightingHigh Power LED Street Lights
Specification:
| Product name | LED street light |
| Style NO. | MH-60W |
| Body material | Aluminum |
| LED Power LED | 60W |
| LED Quantity | 30W*2pcs |
| Input Voltage | AC85-265V |
| LED luminous | 5000-6500Lm/1pcs |
| LED chip | Puri chip |
| Luminous effect | ≥130lm/W |
| Lamp size | 540*340*180mm |
| Packing size | 580*350*195mm |
| Working temperature | -40ºC~+60ºC |
| Working Humidity | 10%~90% |
| Light color | White/Warm white |
| Color temperature | 5500-6500K |
| CRI | Ra>75 |
| IP Grade | IP65 |
| Beam Angle(Degree) | H:136.3° V:127.6° |
| Light distribution curve | Bat wing |
| Central Illumination | H:8m 42LUX H:10m 27LUX |
| Effective illumination area | H:8m 28*8m² H:10m 35*10m² |
| Working life | >50000hrs |
| N.W. | 5.3KG |
| Warranty | 2-5 years |
NOTE: 120w LED is equal to 250w sodium lamp
One piece die-cast aluminum, the back of lamp body is blade fins, cooling capacity is strong and effective guidance of rain, no water, maintenance-free, 120-degree wide-angle lens with high temperature acrylic
| Item No. | Power (W) | LED Lamp beads Qty | Module Qty | Luminous Effecacy | Luminous Flux | Warranty | Dimension |
| MH-30W | 30 | 30 | 1 | 110-130lm/w | 3000-4500Lm | 3-5 years | 460*340*180 |
| MH-60W | 60 | 60 | 2 | 110-130lm/w | 5000-6500Lm | 3-5 years | 540*340*180 |
| MH-90W | 90 | 90 | 3 | 110-130lm/w | 6000-9900Lm | 3-5 years | 615*340*180 |
| MH-120W | 120 | 120 | 4 | 110-130lm/w | 9900-13200Lm | 3-5 years | 710*340*180 |
| MH-150W | 150 | 150 | 5 | 110-130lm/w | 13200-16500Lm | 3-5 years | 795*340*180 |
| MH-180W | 180 | 180 | 6 | 110-130lm/w | 16500-19800Lm | 3-5 years | 875*340*180 |
| MH-210W | 210 | 210 | 7 | 110-130lm/w | 19800-23100Lm | 3-5 years | 960*330*180 |
Storage Environment
| Storage Temp | -20ºC~+55ºC |
| Working Temp | -20ºC~+45ºC(25ºC Working Best) |
| Working Humid | 40-90%RH |
Applications:
1.Tunnel, Subway, Underground Lighting;
2.Gymnasium, Sports Stadium Lighting;
3.Building, Billboard Lighting;
4.Gas Station, Garage Lighting;
5.Park, Garden Lighting;
6.Workshop, Factory Lighting;
7.Warehouse, Storage Lighting;
8.Yard, Square Lighting;
9.Road, Highway Lighting;
10.Station, Dock Lighting etc
Payment terms&Shipping
1. Sample order, Small order, we accept payment via T/T, Western Union.
2. Bulk order: 30% T/T in advance, 70% balance before shipment.
3. After your payment,we could send out the goods within 15 days, if out of stock,need to wait more time,but we will inform you before your payment. For Bulk order, it'll take 20-30 days for production.
4. Considering the security, we recommend DHL, FEDEX, UPS, (EMS only for Russia), which only take 4-7 days delivery time, EMS 5 days around longer.
What purchaser can get from us:
1. Small MOQ, Short Lead Time. (Sample order 3 days if have stock, formal order 15-20 days).
2. Customized packing carton or our nice designed new export neutral cartons. Order up to one container, can do 1-2 color logo on cartons. All products well packed for you.
3. Good serviceduring whole process, will follow the order process at every step, and send product photo to clients for checking before shipment.
4. Have our ownProfessional Engineer Team, and help you design your lighting system, and made some modification to current exsited models. Also can open mold as your requested.
===Feature===
1. CE and RoHS approved.
2. Stretched aluminum casing and high intensity toughened glass cover
3. High efficiency and power factor LED driver
4. Wide radiation angle, huge lighting area
5. Start without delay and flicker free
6. Good color rendering
7. Warm and cold color temperature are available
8. High shock & vibration resistant
9. Ideal heat dissipation design
10. No UV & IR, No Blinking and No Mercury & Lead free
11. Patented fixture design and LED package technology
12. Energy saving system, saving 50% energy than the conventional Metal halide lamp, Sodium Light or HPS light
Warranty term
1, Under the terms of this warranty, if the products have a failure occurs under normal usage within warranty period, Taiding Light will provide free new products based on the proof-documents
2, If Failure or damage due to incorrect operation, wire connection, or anything other do not follow our instruction, Taiding Light will provide paid maintains within warranty period.
Hello Sir,
Happy found you are well. And got to know you need to purchase street lights.
Can you tell us your request for products? Telling us would reduce your worry.
We (Bright Electrics Co.)are professional manufacturer for lights,who would provide the best service. Please contact us freely for business.
Thanks for your time.
Wenzhou Bright Electric Co., Ltd. is located in the famous city - Wenzhou, is engaged in road and LED application products research about products, development, design and manufacture of high-tech enterprises. The company has advanced LED module production line, LED light source production line, LED lighting appliances assembly lines, street light pole production line can produce a variety of street sales of housing, and lights products.
Quality and credibility, reputation and development is our aim to implement. Production strictly, sales tracking service, so that strict quality assurance system and powerful manufacturing standards of innovation, quality, price, service and satisfaction enough to reassure customers, to ensure that products manufactured passing rate of 99.9 percent, 99.9 percent satisfaction rate products.
Wenzhou Bright Electric Company solemn promise: Customers on product quality and service requirements, really our fate and future of the business value of their own pursuit. We are guided by the principle of sincere cooperation, the light forming colleagues, let us sincerely work together to revitalize national industry, and constantly open inside, brilliant in the new century.
Professional production of lights, spot lights, floodlights, garden lights, LED lights, lawn, landscape lights and other outdoor lighting, you can always send e-mail asking us product information.
