Technical Parameters:
Model: ZY-BS280
Electrical
Power supply: Electronic auto-ranging
Input voltage range: Supply 100-250V, 50/60Hz
Power consumption: 470W
Optic
Light source: OSRAM HRI 280W Lamp
LED life expectancy: 2200 hours
Lens: High precision optical lens
Strobe: Dual lens strobe (0.5-9times/second)
Dimmer: Smooth dimmer from 0-100%
Feature
Color wheel: 13 color+white
Rotating gobo wheel: 9 gobos+ white
Static gobo wheel: 14 fixed gobos+white
Prism 1: 8-facets circular rotating prism
Prism 2: 6-facets linear rotating prism
Zoom: 2.5° -20°
Focus: Linear adjustment
Motorized
Pan/Tilt
Pan movement range: 540°
Tilt movement range: 270°
8bit/16 bit movement solution, optional
Automatic Pan/Tilt position correction
Pan movement 0° -540° At max...
Tilt movement 0° -270° At max...
LCD operation
Built-in demo sequences
Silent fans cooling
Strong two-phase motors
Stand-alone operation
Supported protocols: DMX512
2 DMX modes (16/24 control channels)
Connection
DMX data in/out: Locking 3-pin and 5-pin XLR
AC power input: 1.5m power cord with plug
Rigging
Mounting points: 2 pairs of 1/4-turn locks
Mounting horizontally or vertically via 2 Omega brackets
Temperatures
Maximum ambient temperature: 45º C
Maximum housing temperature: 75º C
Minimum distances
Min. Distance from flammable surfaces: 3.0m
Min. Distance to lighted object: 2.0m
Dimension: 386(L) x 365(W) x 589(H) mm
Weight (net): 19kg
Warranty: 2 Year
Accessories: User Manual, 1 pcs; safety cord, 1 pcs; clamp, 2 pcs; 1.5-meter-long signal wire, 1 pcs
Guangzhou CN Eagle Lighting Co., Ltd. is a high-tech company, which is engaged in R&D, manufacturing and marketing of stage equipments.
The main products include moving head beam, LED stage light, follow spot, LED PAR Lights etc.
We own a professional R&D team, who has about 10 more years experience in stage lighting.
Our sales team can provide best service by engineers and technical staff members' supporting.
Most of our products have passed CE quality management system standard as well.
There are numerous domestic projects we have been undertaken, was praised by all the customers.
Our main products are 200W/230W/280W/330W 5r/7r/10r/15r moving head beam, 19 X 15W bee eye LED moving head, 36/37 X 15W LED moving head, 54 X 3W LED PAR/ non-waterproof LED PAR,
8 X 12W LED moving spider light etc,
Our lighting are suitable for stage event, concert, studio, night club, disco, architectural, karaoke television we currently provide comprehensive service and customer support to over 40 international countries and regions.
We offer high quality products, best after-sales service, fast shipment.
Customer First! We always strive to exceed the customer's expectation. We go thogether to become the leading stage lighting supplier on a global maket.
