Product Specification:
1. Materail: Aluminum alloy + PC (Clear PC, Frosted PC and Strip PC available)
2. Input Voltage: 85-285V AC
3. Work Frequency: 50-60Hz
4. Power Factor: Beyond 0.92
5. Lighting Efficiency: Beyond 85%
6. Color Rendering Index: Beyond 75%
7. Efficacy: Above 90LM/W
8. Constant Circuit Error: Less than 2%
9. Static Power Consumption: Less than 0.5W
10. Ambient Temperature: -20-85 degree
11. Microwave/Noise: Less than 240mV
12. Short Circuit Protection: Available
13. Color temperature: 3000-20000K available; Such as Warm white: 3000-3500K; Day White: 6000-6500K; Cold White: 6500-7000K
14. Other color available: Red, green, blue, yellow, RGB etc
15. Adopt super brightness Dip or SMD (3528) LED as light source; Chip brand: Epistar (made in Taiwan)
Instruction:
1. The above mentioned data is based on the pure white(CT6500K) light at the distance of 1.5m position. Many colors such as R/G/B/P etc and DIP OR SMD LED is available.
2. The product uses widely in shop sales counter, warehouse, super market, and advisement lighting.
Item No |
Wattage(W) |
LED quantity |
Luminous flux(LM) |
Dimension(mm) |
GP-L05RGAB |
5W |
72 |
450 |
344*26 |
GP-L06RGAB |
6W |
108 |
540 |
602(595)*26 |
GP-L08RGAB |
8W |
144 |
720 |
602(595)*26 |
GP-L09RGAB |
9W |
171 |
810 |
602(595)*26 |
GP-L10RGAB |
10W |
189 |
900 |
906*26 |
GP-L12RGAB |
12W |
216 |
1080 |
1212*26 |
GP-L15RGAB |
15W |
276 |
1350 |
1212*26 |
GP-L18RGAB |
18W |
330 |
1620 |
1212*26 |
GP-L22RGAB |
22W |
384 |
1980 |
1212*26 |
GP-L25RGAB |
25W |
432 |
2250 |
1512*26 |
GP-L33RGAB |
33W |
600 |
2970 |
2382*26 |
Shenzhen Gaopin Semiconductor Lighting Technology Co., Ltd., located in Shenzhen, China, is a high-tech enterprise which is engaged in designing, researching, producing, and selling all kinds of LED, LED lighting products, LED energy saving lights, LED tubes. We have a high quality and professional team. We imported abroad complete automatic producing devices, which can ensure our products are of high quality and competitive price.
In the efforts of all the colleagues, our company have successfully certificated with the ISO9001: 2000 quality system certification standard. Our products has passed CCC, CE, ROTHS, UL certification and obtained national intellectual property (practical and new patent ZL200820092090.1 and design patent 200830101731.0)
At the present, with an extensive salas and distribution network in China and o list of long-term customers from Europe, the Americas, Asia, Australia and Africa. We provided many kinds of constant current LED fluorescents with different powers and specifications. GAOPIN becomes the LED fluorescent experts and leads the green lighting pioneer. Let GAOPIN light the world. LED lights are colorful, super -high illumination, longer life, environmental, energy saving, and they are meeting the requirement of green life.
GAOPIN has always been dedicated to the user good quality products and excellent service is that in the future, will further enhance product development and quality continue to improve and perfect the major pre-sales and after-sales service, be sure to meet the needs of every consumer, full lighting to create a new type of modern enterprise. GAOPIN will accompany you at a bright future!
