Led stage wash light
LED BAR PRO RGBW
TECHNICAL SPECIFICATIONS:
Power supply: 90-240V AC 50/60Hz
Power consumption: 200W
DMX-control-channels: 9
DMX-512-connection: 3-pin XLR
Number of LED: 24 high MCD 4 in 1 8W RGBW LEDs
Dimensions: 410*190*70mm
Weight: 6kgs
DETAILED PARAMETERS:
Electronic power supply AC 90-240V 50/60Hz
Full Master/Slave operation in any operational mode,
Color strobe effect and long life operation
Black housing with 24*high MCD 8W LEDs RGBW four in one
Producing various colors, red, green, blue, yellow, white, pink, purple, cyan
Low heat, Long Life LEDs (100, 000 hrs. )
Operational Modes: DMX 512 protocol, Sound Active, Auto, master/slave
Color strobe effect slow to fast, electronic dimming from 0-100%
Uses 9 DMX Channels
Stand Alone, Master/Slave
Linkable via 3-pin XLR cable, hanging brackets included
Dual brackets allowing fixture to be hung or set on the ground
4-digital LED display
ITEM DIMENSION: 41*19*7CM
ITEM WEIGHT: 6KGS
OUR SERVICE:
1. Your inquiry related to our products or prices will be replies in 24 hours.
2. OEM&ODM, any your customized lightings we can help you to design And put into product without any charges
3. Shipping method: DHL, UPS, FedEx, TNT door to door service, by sea, by air, etc
4. Promised After-sales Service
5. Definitely high brightness with good material inside
6. Customised LED Quantity Design
|
NINE DMX channels |
|
Channel 1 |
red from small to big brightness (dimming) |
|
Channel 2 |
green from small to big brightness (dimming) |
|
Channel 3 |
blue from small to big brightness (dimming) |
|
Channel 4 |
white from small to big brightness (dimming) |
|
Channel 5 |
master dimmer from small to full brightness |
|
Channel 6 |
strobe from slow to fast |
|
Channel 7 |
dimmer,color macro |
|
0-30 |
dimmer on at ch1/ch2/ch3/ch4 |
|
31-255 |
color macro, the brightness can be adjusted by the master dimmer at ch4 |
|
Channel 8 |
dimmer, increasing brightness, then decreasing brightness, colors following one by one |
|
0-85 |
dimmer on at ch1/ch2/ch3/ch4 |
|
86-169 |
increasing brightness, then decreasing brightness, the running speed can be adjusted by ch8 |
|
170-255 |
color following one by one, the running speed can be adjusted by ch8 |
|
Channel 9 |
running speed adjustments |
