1. Function and Technology Character
(1) Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
(2) Information source can be camera, video, VCD, DVD, LD, TV and so on.
(3) Clear picture without flicker and distortion.
(4) Brightness, contrast, saturation can be adjust by itself and manual.
(5) Show everything with your PC does synchronously.
(6) Super correcting technology for distortion.
(7) One interface for sound signal and two for video signal at least.
(8) Connected and controlled by PC via Lan and remote control.
(9) Multiform language editions, such as English, French, Germany, Greek, Russian and so on.
|
Display and Control Feature |
Structure Feature |
|
Specification |
Parameter |
Specification |
Parameter |
|
Pixel Pitch |
10mm |
Module size |
320mm* 320mm |
|
Pixel composing |
1R1G1B |
Display resolution/module |
32 dots* 32 dots |
|
Wavelength (R) |
625±5 |
Standard cabinet size |
960 mm*960mm |
|
Wavelength (G) |
522±3 |
Weight per sqm |
50 Kg/sqm |
|
Wavelength (B) |
567±3 |
Protection classification |
--- |
|
Wave Angle (H) |
120°(H)/120°(V) |
Install mode |
Wallmount, hung and stand structure |
|
Led package |
3in 1 Dot-Matrix |
|
|
|
Density |
10,000 |
Working Power |
|
Display color |
256*256*256 |
Specification |
Parameter |
|
Whiteness brightness |
500 - 650 cd/sqm |
Working voltage |
AC 220v/380v±10% 50~60Hz |
|
Brightness level |
128 grade |
Max power/sqm |
5900W/sqm |
|
Changing frame frequency |
60 Hz |
Average power/sqm |
170W/sqm |
|
Refresh |
215/400 Hz |
Short circuit protection |
Yes |
|
Driving method |
Constant driving 1/8 |
|
|
|
Control mode |
synchronous |
Working Environment |
|
Display port |
DVI |
Specification |
Parameter |
|
Display mode |
1024*768 1024*1024 |
Environment |
Indoor |
|
Out of control |
1/10,000 ( scattered) |
Working temperature |
--10~50 C |
|
lifetime (Full white-half brightness) |
45,000 hours |
Working Humidity |
10~90% |
As a Proffessional led lights & led display products manufactuer, Pingwei Technology Limited was established in 2002 in intergrading the R&D, manufacturing and sale of 2 series, Led lights, led display ) more than 70 items products, including Led lights and led display. The products such as Led tube, led panel lights and led display. Our factory in Shenzhen China, occupies a floor area of 20, 000square meters with 4 production lines and a labor force of more than 500 employees. Over 9 years experience has given us the confidence to guarantee the quality of our products., keep improving manufacturing efficiency is the spirit of our daily operation. All our management is organized according to ISO9001: 2000, thus all of our products are produced to the strict standards. Stable quality and reasonable price help us enjoy high reputation from our customers all over the world and China.
PINGWEI also enjoys a very strong self-collocation capacity, it has its own SMT lines, Led lights, Led display assembly lines and modern finished goods assembly lines, which can strictly control the quality from the very begining to the delivery of goods, and can properly decrease the cost as well.
We have established good relationship with many foreign company, we are also looking for good partner in all of the world.
We are promoting our own brand name and accepting OEM orders and providing the total solutions to our customers. We are esteem and develop the mutual benefit between our suppliers and customers as the strategic partners. Only the Win-Win Policy can enlarge and streng then our own supply and demand chain cycle in this LED industry. Back up by the ISO9001: 2000 factory in China, we are producing our led products in house by our 3 High speed SMT machines. All of our products have to be passed the strict QA and QC testing program before delivery. Made the product reliability, we are worthy your trust. Now, start with us, you will find a new Led lights, Led display partner in China.
