Function and Technology Character
(1) Multiplied file formats, such as AVI, MOV, MPG, DAT, VOB are comprehensive, and also we have three display mode as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal.
(2) 4096 grade grey control system and the color is over 16.7 millions, and the brightness, contrast, saturation, chroma can be adjusted by manual and sensor, whose scope is 256 grade.
(3) Show all kinds of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously.
(4) Line-Double technology is adopted for the picture adjustment.
(5) Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL.
(6) Can be used outdoor in all kinds of weather, and excellent capability of antisepsis, waterproof.
|
Display and control feature |
Structure feature |
|
Specification |
Parameter |
Specification |
Parameter |
|
Pixel Pitch |
31.5 mm |
Module size |
125 mm*250 mm |
|
Pixel composing |
4R2G2B |
Display resolution/module |
4 dots*8 dots |
|
Wavelength (R) |
625± 5 |
Standard cabinet size |
1000 mm*1000 mm |
|
Wavelength (G) |
522± 3 |
Weight per sqm |
65 Kg/sqm |
|
Wavelength (B) |
567± 3 |
Protection classification |
IP65 |
|
Wave Angle (H) |
140° (H)/ 60° |
Install mode |
Wallmount, hung and stand structure |
|
LED package |
DIP546 |
Cabinet Material |
Iron/Aluminum |
|
Density per sqm |
1026 pixel |
Working power |
|
Display color |
256*256*256 |
Specification |
Parameter |
|
Whiteness brightness |
≥ 7500cd |
Working voltage |
AC 220v/380v± 10% 47~64Hz |
|
Brightness level |
128 grade |
Max power/sqm |
850W/sqm |
|
Changing frame frequency |
60 Hz |
Average power/sqm |
400W/sqm |
|
Refresh |
400 Hz |
Short circuit protection |
Yes |
|
Driving method |
Constant Static |
Led Lamp type |
Nichia/Cotco/Cree/Axt/Silan/Taiwan |
|
Control mode |
synchronous |
Working environment |
|
Display port |
DVI |
Specification |
Parameter |
|
Display mode |
1024*768 /1024*1024 |
Environment |
Outdoor |
|
Out of control |
1/10, 000 ( scattered) |
Working temperature |
--20~50 C |
|
lifetime |
100, 000 hours |
Working Humidity |
10~90% |
As a Proffessional led lights & led display products manufactuer, Pingwei Technology Limited was established in 2002 in intergrading the R&D, manufacturing and sale of 2 series, Led lights, led display ) more than 70 items products, including Led lights and led display. The products such as Led tube, led panel lights and led display. Our factory in Shenzhen China, occupies a floor area of 20, 000square meters with 4 production lines and a labor force of more than 500 employees. Over 9 years experience has given us the confidence to guarantee the quality of our products., keep improving manufacturing efficiency is the spirit of our daily operation. All our management is organized according to ISO9001: 2000, thus all of our products are produced to the strict standards. Stable quality and reasonable price help us enjoy high reputation from our customers all over the world and China.
PINGWEI also enjoys a very strong self-collocation capacity, it has its own SMT lines, Led lights, Led display assembly lines and modern finished goods assembly lines, which can strictly control the quality from the very begining to the delivery of goods, and can properly decrease the cost as well.
We have established good relationship with many foreign company, we are also looking for good partner in all of the world.
We are promoting our own brand name and accepting OEM orders and providing the total solutions to our customers. We are esteem and develop the mutual benefit between our suppliers and customers as the strategic partners. Only the Win-Win Policy can enlarge and streng then our own supply and demand chain cycle in this LED industry. Back up by the ISO9001: 2000 factory in China, we are producing our led products in house by our 3 High speed SMT machines. All of our products have to be passed the strict QA and QC testing program before delivery. Made the product reliability, we are worthy your trust. Now, start with us, you will find a new Led lights, Led display partner in China.
