Main technical parameters
Power supply
Ø Rated Voltage: AC90~240V
Ø Rated Frequency: 50~60Hz ± 10%
Ø Rated Power: 350W
LED
Ø LED Type: 25pcs × 12W Cree RGBW 4in1 full-color super bright LED
Ø Drive Current: 700mA
Ø Colors: 16.7 million colors (0~100% saturation dimming)
Ø Life: 50000 hours
Control
Ø Control Protocol: International standard DMX-512 signal
Ø Channel: 20CH/120CH
Ø Control Mode: DMX-512, sound, auto-program mode, master-slave mode, LCD display
Optical System
Ø Pattern: 32 dynamic pattern, 45 fixed pattern (including Arabic numbers, uppercase letters)
Ø Pan movement: 580, 8bit/16bit adjustable, electronic error correction
Ø Tilt movement: 270 (360 ), 8bit/16bit adjustable, electronic error correction
Ø Dimmer: From 0~100 linear dimming
Ø Strobe: 0-15 / sec, adjustable (electronic strobe)
Ø Beam angle: 8° / 20° Optional
Physical
Ø Dimensions: 580 * 435 * 625mm
Ø Weight: 23kg
Ø Housing color: Black (Can be customized)
Ø Connection: Signal cable IN/OUT, power cable IN
Security
Ø Cooling System: Fan convection mode
Ø Temperature Protection: Intelligent temperature overheating protection and anti- jamming electronic circuit. Intelligent heat dissipation.
Ø Operating Environment: Indoor
Ø Working Temperature: -20° C~40° C
