Technology parameters:
1. The protective level: IP65
2. Light source: Size power single/integrated LED
3. The rated voltage and frequency: 220 V (± 10%)/ 50Hz
4. Install pipe diameter: 60mm
5. High pressure casting aluminum forming shell, external electrostatic pensu processing
6. High purity aluminum plate type made reflector, the surface anode oxidation process
7. Stainless steel clasp, stainless steel fasteners bolt, nut
8. Pervious to light cover the high strength glass surface
9. High temperature resistant silicon rubber seal belt
Product features:
1. Use imported or high quality high brightness domestic LED chips, no ultraviolet and infrared, photosynthetic efficiency higher, more stable;
2. Using high thermal conductivity LED encapsulation technology and more recessed cooling technology, effectively reduce the lamps thermal resistance, chip junction temperature can be controlled in a 60 Degrees Celsius, ensure that core lamps and long life;
3. Using high thermal conductivity aluminum radiator, and the surface of the corrosion resistant heat superconducting anode shading oxidation technology to ensure that LED light source heat generation of faster send out;
4...Using two optical imaging lens and not specifically for spectrum and LED a high pervious toughened glass chimney, ensure the lamps light rate as high as 85%;
5. Adopt AC voltage input voltage of wide constant current drive, ensure that apply to the lamps different country and region, and high power factor, the harmonic small;
6. Using the United States gore respirator, ensure dustproof, waterproof, keep pressure balance, eliminate condensation phenomenon;
7. Lamps by professional appearance design aesthetics, concise, easy and fashion.
Application:
Trunk road, sub trunk road, branch, square, community, etc.
Model No. |
Power |
LED Lumens |
Color Temperature |
LED Chip |
Work Voltage |
KHSL-W30 |
30W |
100-110LM/W |
2700-7000K |
Optional |
AC85-265V |
KHSL-W60 |
60W |
100-110LM/W |
2700-7000K |
Optional |
AC85-265V |
KHSL-W90 |
90W |
100-110LM/W |
2700-7000K |
Optional |
AC85-265V |
KHSL-W120 |
120W |
100-110LM/W |
2700-7000K |
Optional |
AC85-265V |
KHSL-W150 |
150W |
100-110LM/W |
2700-7000K |
Optional |
AC85-265V |
|
|
|
|
|
|
