Lathe Aluminum factory led down light
CE Rohs approved 8 inch recessed COB 3/5/7/9/12/15/18/25/30W LED down light ,led recessed ceiling light with 200mm cutout
1. Epistar COB LED CHIP ,RA<80
driver With CE/C-tick/SAA/RoHS Approval
2. Low power consumption, High power efficiency
3. Good heat dissipation function, stable performance.
4. High quality with 3 years guarantee for 20w led down light CE Rohs approved
5.LED COB Downlights saving up 80% on your energy usage, comparing to the traditional ones.
| tem No. | EP-DL-3W/5W | EP-DL-5W/7W | EP-DL-7W/9W | EP-DL-10W/15W | EP-DL-15W/20W | EP-DL-25W/30W |
| Watt | 3W-5W | 5W-7W | 7W-9W | 10W-15W | 15W-20W | 25W-30W |
| Inch | 2.5" | 3" | 4" | 5" | 6" | 8" |
| Lumen | 90-100LM/W | 90-100LM/W | 90-100LM/W | 90-100LM/W | 90-100LM/W | 90-100LM/W |
| Input Voltage | AC 85-265V | AC 85-265V | AC 85-265V | AC 85-265V | AC 85-265V | AC 85-265V |
| Size | Ø85*50mm | Ø95*50mm | Ø131*50mm | Ø165*50mm | Ø190*60mm | Ø220*60mm |
| Cutout Size | Ø55 | Ø85 | Ø110 | Ø140 | Ø170 | Ø200 |
| Beam Angle | 120 degree | 120 degree | 120 degree | 120 degree | 120 degree | 120 degree |
| LED Type | 1PS COB 14mm | 1PS COB 14mm | 1PS COB 30mm | 1PS COB 43mm | 1PS COB 60mm | 1PS COB 60mm |
| Power Factor | >0.9 | >0.9 | >0.9 | >0.9 | >0.9 | >0.9 |
| CRI | Ra>80 | Ra>80 | Ra>80 | Ra>80 | Ra>80 | Ra>80 |
| CCT | 2800K, 3000K, 4000K, 5000K, 6 |
| Housing material: | Aluminum+Glass |
| Lifespan: | >50000 Hours |
| Warranty | 2 years |
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
